Help CenterSoft Pvc Pipe Winder Machine/pe Pipe Winder
Related Products
Specifications
Soft pvc pipe winder machine/pipe winder1.for soft pipes ,sheets,films ect.
2.easy to operate and clean
3.high quality
Soft pvc pipe winder machine/pe pipe winder
Performance and features:
1. This plane is mainly applied to aluminum-plastic composite pipe, the jacket line, PE pipe rolling, it can be extruder, gutters, ink pad printing machines, such as traction to form a well-set production lines. The machines reel breakdown rack sides were installed in the use of two or reel spindle on the electromagnetic clutch of the two winding turn, and in the intermittent time in the discharge, with the continuity of the production, winding neat features.
2. Main technical standards
Winder Disk NO. |
2 |
Winder Disk Inner Diameter (mm) |
¢540~¢1600 |
Largest Winding Diameter (mm) |
¢2100 |
Winding Width (mm) |
350 ~ 400 |
Spindle Speed (double speed) |
11rpm (max) / 130 rpm (max) |
Largest Winding Size |
63 |
Torque motor |
10N.m/25 N.m |
Wire |
Wire Rod (0-70 ) |
Discharge |
Pneumatic necking |
Air pressure |
0.6Mpa |
Dimensions |
L3600 × W2600 × H2610 |
