Good Quality High Standard Cement Bucket Elevator With Best Price
Descriptions of Bucket Elevator:
1.Cement Bucket Elevator can elevate a variety of bulk materials from light to heavy and from fine to large lumps.The bucket elevator is the enabling technology that permitted the construction of grain elevators.
2.A diverter at the top of the elevator allows the grain to be sent to the chosen bin. It is a similar device with flat steps is occasionally used as an elevator for humans, e.g., for employees in parking garages. (This sort of elevator is generally considered too dangerous to allow use by the public.)
The Cement Bucket Elevator Consists of:
1.Means to drive the belt;
2.A belt to carry the buckets and transmit the pull;
3.Buckets to contain the material;
4.Accessories for loading the buckets or picking up the material, for receiving the discharged material, for maintaining the belt tension and for enclosing and protecting the elevator.
Early bucket elevators used a flat chain with small, steel buckets attached every few inches. Current construction uses a rubber belt with plastic buckets. Pulleys several feet in diameter are used at the top and bottom. The top pulley is driven by an electric motor.
Technical parameters:
Model |
D160 |
D250 |
D350 |
D450 |
HL300 |
HL400 |
TH315 |
TH400 |
TH500 |
|
Type |
Rubber belt |
Rubber belt |
Rubber belt |
Rubber belt |
Link Chain Centrifugal |
Link Chain Centrifugal |
Link Chain Centrifugal |
Link Chain Centrifugal |
Link Chain Centrifugal |
|
Capacity(m3/h |
Deep bucket(S)(L) |
8 |
21.6 |
42 |
69.5 |
28 |
47.2 |
59 |
94 |
118 |
Shallow bucket(Q)(L) |
3.1 |
11.8 |
25 |
48 |
16 |
30 |
35 |
58 |
73 |
|
Bucket capacity |
Deep Bucket(S)(L) |
11 |
3.2 |
7.8 |
15 |
5.2 |
10.5 |
6 |
9.5 |
15 |
Shallow bucket(Q)(L) |
0.65 |
2.6 |
7 |
14.5 |
4.4 |
10 |
3.75 |
5.9 |
9.3 |
|
Conveyor width(mm) |
200 |
300 |
400 |
500 |
||||||
Bucket distance(mm) |
300 |
400 |
500 |
500 |
600 |
512 |
512 |
688 |
||
Bucket width(mm) |
160 |
250 |
350 |
450 |
300 |
400 |
315 |
400 |
500 |
|
Running speed(m/s) |
1 |
1.25 |
1-25 |
1.25 |
1.25 |
1.25 |
1.4 |
1.4 |
1.5 |
|
Shaft speed(r/min) |
47.5 |
47.5 |
47.5 |
37.5 |
37.5 |
37.5 |
42.5 |
37.6 |
35.8 |
|
Max.Feeding Size(mm) |
25 |
35 |
45 |
55 |
40 |
50 |
35 |
40 |
50 |
|
Lift Height(m) |
4-30 |
4-30 |
4-30 |
4-30 |
4.5-30 |
4.5-30 |
4.5-30 |
4.5-30 |
4.5-30 |
|
