Best Price Hot Saling PPCS Pulse Bag Filter With CE/ISO Approved

Specifications

PPCS Pulse Bag Filter
1)Features:high efficiency and long service life,working temperature:<120,etc;
2)Capacity:8930m3/h.

Best Price Hot Saling PPCS Pulse Bag Filter With CE/ISO Approved

The Introduction of PPCS Pulse Bag Filter:

PPCS  air case pulse bag filter(dust collector) is widely used in the dust collect systems,such as crushing, package, roof, plastic cooling and mills of the cement plant, and the waste gas of metallurgy, chemical machinery and civil boiler etc.The bag filter is an efficient bag filter, which is imported from United States. It integrates sub-room cleaning and spray dedusting, and other advantages. It overcomes the disadvantage of sub-strength sub- room dedusting in little strength, simultaneous spray pulse dedusting and filtering, thus expands the applications of gas box pulse bag filter.

The Main Features of PPCS  Air Case Pulse Bag Filter:
1.PPCS pulse bag filter can be widely used for dust collecting in cement plant for crushing, packing and crushing.

2.It also can be used in metallurgical,chemical.machinery and other civilian boiler exhaust  ESP.

3.Outdoor installation by different kits comprising a variety of different specification .The whole  series has 8 different specification in total with 130mm diameter of collector and 2000mm length.

4.Continuous use temperature less than 120.

5.High dust collecting efficiency. Dust concentration less than 100mg/m³.

6.The bag fileter  has high efficiency dedusting and long service life.

The Main Technical Parameters of the Dust Collector:

Model	Air flow rate	Total filter area	Chamber qty	Quantity of filter bag	Pulse Valve		Compressed air consumption	Weight (without insulating layer)
					Quantity	Spec.
	(m³/h)	(m2)	(pcs)	(pcs)	(pcs)	(inch)	(N m³/min)	(kg)
PPC32-4	8930	124	4		4		0.37	3400
PPC32-6	13390	186	6		6		0.55	5400
PPC64-4	17800	248	4	64	4	2 ½	1.2	6900
PPC64-6	26700	372	6		6		1.8	9700
PPC64-8	35700	496	8		8		2.4	12500
PPC96-4	26800	372	4	96	4	3''	1.2	8710
PPC96-6	40100	557	6		6		1.8	12400
PPC96-8	53510	744	8		8		2.4	15700
PPC96-12	80400	1023	12		12		3.4	25200
PPC128-6	67400	936	6	128	12		3.5	20100
PPC128-8	89870	1248	8		16		4.8
PPC128-10	112100	1558	10		20		6.0	28900
PPC128-16	179700	2496	16		32		9.5	50000
PPC128-20	224600	3120	20		40		12	60000
