1.Application of magnetic separator
The Magnetic Separators are available in cyclic design with vessel whose diameters are smaller than 3mm. Magnetic Separator is a kind of efficient equipment for processing fine, feebly magnetic minerals, such as hematite, limonite, wolfram, limonite, and tantalum-niobium, etc. In recent years, it is also more and more applied in purifying quartz, feldspar and nephrite. Its magnetic system is a ring-shape chain closed magnetic circuit with energizing coils made of copper tube and cooled internally by water. Grooved plates made of magnetic conductive stainless steel are used as magnetic matrix.
Magnetic separator are applied for mining, coal preparation plant and other occasions for iron, iron removal operations.The magnetic field distribution characteristics of this series devices is good for the recovery effect of fine powder, make the recovery rate of the magnetic minerals greatly improve .
Its magnetic system, using high quality ferrite material or compound is made with rare earth magnet and the average magnetic flux density of drum table is 100 ~ 600mT. According to user's needs , providing downstream, semi-countercurrent, counterflow, and other magnetic separation of the different tables.
2.Advantages of magnetic separator
1) Short magnetic circuit,
2) little magnetic flux leakage
3) high magnetic intensity
4) low energy consumption
5) fine beneficiating results
3.Parameters of magnetic separator
| Model | D*L(mm) | Magnetic Field Strength(mT) | Yield(m3/h) | Rotated Speed(r/min) | Motor Power(Kw) | Weight(Kg) |
| CT12/30N | 1200*3000 | 200 | 260-350 | 19 | 7.5 | 6837 |
| CT12/27N | 1200*2700 | 200 | 230-310 | 19 | 7.5 | 6750 |
| CT12/24N | 1200*2400 | 200 | 200-275 | 19 | 7.5 | 6270 |
| CT10.5/30N | 1200*3000 | 200 | 220-300 | 21 | 5.5 | 6900 |
| CT10.5/27N | 1050*3000 | 200 | 190-270 | 21 | 5.5 | 6350 |
| CT10.5/24N | 1050*2400 | 200 | 170-240 | 21 | 5.5 | 5760 |
| CT10.5/21N | 1050*2100 | 200 | 150-210 | 21 | 5.5 | 5177 |
| CT10.5/18N | 1050*2100 | 200 | 130-180 | 21 | 5.5 | 4560 |
About us
Henan Kefan Mining Machinery Co., Ltd is a modern and high-tech enterprise established with a state level research.Since established in 1980,We have passed ISO9001:2008 quality system authentication and CE certificate.
Before customers' purchase, we will send our engineers to customers' site to design the best flow chart; after purchase, we will send the engineer to guide to install the machine, take trial run. Try our best to provide our customers with service of high quality and high efficiency. We welcome customers from home and abroad to visit our company and carry out cooperation!
We are professonal magnetic separator supplier, producing wet & dry type magnetic separator.The machines were certificated with CE/BV/ISO. If it's possible, welcome you come and visit our factory, we'll help you make the best choice of the machine you need.Details pls feel free to contact us !!+0086-371-86678090!
