YN 915 Common model:
1. Features:
* Adopt Xinchai C490BG four cylinder engine;
* Full hydraulic transmission technology, simple structure and reliable performance;
* Split flow of single pump for working hydraulic system, significant effect of energy conservation;
* Double sealed hydraulic pipeline joints with 24°awl and O ring of international standard, avoiding oil leakage;
* Load sensing fully hydraulic steering system, easy and flexible operation;
* Safe and reliable single pipeline brake system; Caliper disc brakes.
* Working device with automatically leveling ability at high position.
* Bucket articulated points take sealed, lubricated, dust-proof layers, which owns good durability.
* Integral, luxury instrument board.
* New, luxury cabin.
2.Main Specifications:
Item |
Specifications |
Item |
Specifications |
Bucket capacity |
0.5 m3 |
Min. turning radius (outside of rear wheel) |
3600 mm |
Rated load |
1000 kg |
Steering angle |
35º each direction |
Dumping height |
2420 mm |
Min. ground clearance |
230 mm |
Dumping reach |
900 mm |
Wheel base |
1820 mm |
Boom lifting time |
4 S |
Wheel tread |
1400 mm |
Total cycling time |
8 S |
Engine model |
Xinchai C490BG |
Max. speed |
16 km/h |
Rated power |
32 kW/2400 rpm |
Max. breakout force |
36 kN |
Tire |
8.25-16 |
Max. drawing force |
22 kN |
Overall dimensions |
4960*1620*2420 mm |
Max. grade ability |
28° |
Operating weight |
3400kg |
3. Quality certificate:
(1)CE Approved.
(2)Obtained the certificate of ISO9001:2008.
(3)Manufacturing license number: TS2510025-2009.
4. Quotation:
YN915 Wheel Loader(with 0.5 cbm, 1.0 ton capacity, Chinese Xinchai C490BG engine)
