High Quality Shearing Machine Stainless Steel Plate hs Code QC12Y-20X4000
US$ 6,000 - 11,000
/ Set
1 Set(Min. Order)
- Shenzhen
- T/T Credit Card
You May Like
-
Good Quality Shearing Machine Mild Steel Plate Low Price QC12Y-20X4000
-
Competitive Price Shearing Machine Steel Plate Cutting Machine/plate Steel With High Quality
-
High Precision Shearing Machine Different Types of Steel Plate With Low Prices
-
Hot Hydraulic Shearing Machinery QC12Y-20X4000 Cheap Price
-
China Metal Hydraulic Folding Machine W62Y 3x2500
-
320mm Hot Sale China Slot Machine for Sale B5032 Slotting Machine
Product Details
| Place of Origin | Guangxi, China | Brand Name | Xiashijixie | |
| Model Number | QC12Y-20X4000 | Condition | New | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
High quality shearing machine stainless steel plate hs code QC12Y-20X4000
Product Description
Hydraulic shears is through the use of the main cylinder (fixed to the wall above) do cut down the exercise, nitrogen cylinder return, thus simplifying the hydraulic system, more stable operation. Upper cutter tilting hydraulic shears in the shearing process arc around a fixed axis swing, leverage, fulcrum force is small, can increase the shear blade life, the life of the machine, the machine structure is compact, and the stepless adjustment of the tool carrier itinerary, greatly improve work efficiency.
| Specification | Max.shearing thickness | Max.shearing width | Shearing angle | Ram strokes | Back gauge range | Motor power |
| mm | mm | ° | min | mm | kw | |
| QC12Y-4×2500 | 4 | 2500 | 1°30 | 18 | 20-600 | 4.0 |
| QC12Y-4×3200 | 4 | 3200 | 1°30 | 18 | 20-600 | 5.5 |
| QC12Y-4×4000 | 4 | 4000 | 1°30 | 12 | 20-600 | 5.5 |
| QC12Y-4×5000 | 4 | 5000 | 1°30 | 10 | 20-600 | 5.5 |
| QC12Y-4×6000 | 4 | 6000 | 1°30 | 7 | 20-800 | 7.5 |
| QC12Y-6×2500 | 6 | 2500 | 1°30 | 18 | 20-600 | 7.5 |
| QC12Y-6×3200 | 6 | 3200 | 1°30 | 14 | 20-600 | 7.5 |
| QC12Y-6×4000 | 6 | 4000 | 1°30 | 12 | 20-600 | 7.5 |
| QC12Y-6×5000 | 6 | 5000 | 1°30 | 10 | 20-600 | 7.5 |
| QC12Y-6×6000 | 6 | 6000 | 1°30 | 7 | 20-800 | 7.5 |
| QC12Y-8×2500 | 8 | 2500 | 1°30 | 14 | 20-600 | 7.5 |
| QC12Y-8×3200 | 8 | 3200 | 1°30 | 10 | 20-600 | 7.5 |
| QC12Y-8×4000 | 8 | 4000 | 1°30 | 8 | 20-600 | 11 |
| QC12Y-8×5000 | 8 | 5000 | 1°30 | 7 | 20-800 | 15 |
| QC12Y-8×6000 | 8 | 6000 | 1°30 | 6 | 20-800 | 15 |
| QC12Y-8×8000 | 8 | 8000 | 1°30 | 5 | 20-800 | 15 |
| QC12Y-10×2000 | 10 | 2000 | 1°30 | 12 | 20-600 | 11 |
| QC12Y-10×2500 | 10 | 2500 | 1°30 | 10 | 20-600 | 11 |
| QC12Y-10×3200 | 10 | 3200 | 1°30 | 10 | 20-600 | 11 |
| QC12Y-10×4000 | 10 | 4000 | 1°30 | 8 | 20-600 | 15 |
| QC12Y-12×2000 | 12 | 2000 | 2° | 12 | 20-600 | 15 |
| QC12Y-12×2500 | 12 | 2500 | 2° | 10 | 20-600 | 15 |
| QC12Y-12×3200 | 12 | 3200 | 2° | 9 | 20-600 | 15 |
| QC12Y-12×4000 | 12 | 4000 | 2° | 8 | 20-800 | 18.5 |
| QC12Y-12×5000 | 12 | 5000 | 2° | 7 | 20-800 | 22 |
| QC12Y-12×6000 | 12 | 6000 | 2° | 6 | 20-800 | 22 |
| QC12Y-12×8000 | 12 | 8000 | 2° | 5 | 20-800 | 22 |
| QC12Y-16×2500 | 16 | 2500 | 2° | 8 | 20-600 | 18.5 |
| QC12Y-16×3200 | 16 | 3200 | 2° | 7 | 20-600 | 18.5 |
| QC12Y-16×4000 | 16 | 4000 | 2° | 5 | 20-800 | 18.5 |
| QC12Y-20×2000 | 20 | 2000 | 2°30 | 8 | 20-600 | 22 |
| QC12Y-20×2500 | 20 | 2500 | 2°30 | 6 | 20-800 | 22 |
| QC12Y-20×3200 | 20 | 3200 | 2°30 | 6 | 20-800 | 30 |
| QC12Y-20×4000 | 20 | 4000 | 2°30 | 6 | 20-800 | 30 |
| QC12Y-25×2000 | 25 | 2000 | 3° | 6 | 20-800 | 30 |
| QC12Y-25×2500 | 25 | 2500 | 3° | 6 | 20-800 | 30 |
| QC12Y-25×3200 | 25 | 3200 | 3° | 6 | 20-800 | 37 |
| QC12Y-30×2500 | 30 | 2500 | 3°30 | 6 | 20-800 | 37 |
| QC12Y-30×3200 | 30 | 3200 | 3°30 | 5 | 30-800 | 45 |
| QC12Y-40×2500 | 40 | 2500 | 3°30 | 5 | 30-800 | 55 |
| QC12Y-40×3200 | 40 | 3200 | 3°30 | 5 | 30-800 | 55 |
Detailed pictures for your reference
