CNC Gantry-type Machining Center XH2412
- 30 Set / Sets per Month
- Shenzhen
- T/T
Product Details
Condition: | New | Type: | Horizontal | CNC or Not: | CNC |
Automatic Grade: | Automatic | Max. Swing Diameter: | Depends on Model | Place of Origin: | Guangxi, China |
Brand Name: | XIASHI | Model Number: | XH2412 | Voltage: | 380V |
Power(W): | 15/18.5KW | Dimension(L*W*H): | 7200*4000*4500 | Weight: | 24000kg |
Certification: | ISO9001 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
CNC Gantry-type Machining Center XH2412
Specifications
1. made of premium cast-rion, gantry-type frame structure
2.Highly rigid fixed beam used perpendicular structure rail, provide
Features
1.Basic parts are made of premium cast-rion, gantry-type frame structure, for high rigidity and provide optimum damping properties
2. Highly rigid fixed beam used perpendicular structure rail, provide high rigidity.
3. Heavy duty linear rolling guideway in axis X/Y with advantage of heavy loaded, high precision. Hardened guideway in Z axis ensures rigidity&precison pf feeding in Z.
4.Taiwan high speed spindle unit (8000 rpm), max. spindle speed is 3200 rpm, suitable for low-speed heavy cutting.
5. Suitable for aerospace, automotive, textile machinery, molds, packaging machinery, mining equipment and other precision machining of large workpieces, fit for maching requirements on procedures such as milling, boring, drilling, tapping, etc.
Standard
FANUC 0i MD CNC system
Chain-type tool magazine capability 32 tools
Optional
HEIDENHATN ITNC320 or MITSUBISHI M70 CNC system
Chain-type tool magazine capability 40 tools
Specifications | Units | XH2412 |
Worktable longitudinal travel | mm | 2700 |
Slide carriage transverse travel | mm | 1700 |
Milling head vertical travel | mm | 1000 |
Worktable size | mm | 2500×1250 |
Max. load of worktable | kg | 5000 |
Number/Width/Distance of T-slot | mm | 7-28-160 |
Gantry width | mm | 1750 |
Distance from spindle end to worktable surface | mm | 150-1150 |
Spindle taper |
| BT50 |
Spindle speed | rpm | 30-3200 |
Spindle motor power | kW | 15/18.5 |
X,Y axis Feed speed | mm/min | 1-4000 |
Z axis Feed speed | mm/min | 1-2000 |
X,Y axis fast move speed | mm/min | 12000
|
Z axis | mm/min | 8000 |
X,Y,Zaxis Positioning accuracy | mm | 0.032,0.028,0.025 |
X,Y,Z axis Repeat positioning accuracy | mm | 0.014,0.013,0.012 |
Overall dimension | mm | 7200x4000x4500 |
Machine weight | kg | 24000 |
We will pack the machine with standard export wooden case ,ensure the transport safely
A: You can choose FOB,CIF, DDU or other terms. You can book ship or I can book ship for you.
A: You can make the inquiry online on Alibaba, or send email to us. It is better if you can tell what is your detailed request information. We will reply to you within 2 hours on work days, and within 24 hours on holiday.
A: You can choose machine on our website accodring to your request. Or You can let our seller know what is your request specifcation or what is your parts, so let our seller recommend suitable machine to you. We have do trade machine years, and export machine to over 100 countries. We have CE, ISO, SGS and other quality certificate.
A: We can make the deal on Alibaba online platform, you can pay by T/T or Credit card. You can also pay to my company business bank account. You can also choose L/C or other way.
A: If the machine you will order is standard machine, we can ready the machine within 15days. If special machine, please confirm with our seller. The ship time is about 30 days to Europe, America. If you are from Australia, or Asia, it will be shorter. You can place order according to delivery time and ship time.
A: warranty is one year, but we will offer lifetime service for machine.
