VC600 hard track vertical machining center
Specifications
machining center shaft
CNC milling machine Price
ATC Tool Changer
High speed spindle unit
3 axis or 4 axis
Feature
1.Powerful cutting, low speed high torque,the range of constant power is wide (FANUC AC spindle motor). The main components with high stiffness, bed column saddle are thick bars,
closed-end frame structure. Gearless drives, low noise, small vibrationand thermal deformation.
2.High speed positioning, high speed feed, small vibration, low speed creeping, accuracy high stability.
3.Can be equipped with the fourth axis.
4.Three-guide rails all adopt linear guides , lead screw adopt high-speed ball screw.
5.Three-ball screw, the main electrical components, pneumatic components, lubrication components are imported.
Purposes
Usage
1.it can complete milling, boring, drilling, reaming, tapping and other processes processing .
2.widely applicable to various types of mechanical parts and has a complex shape or mold processing complex cavity.
3.education system is also used for teaching and training of NC and CNC maintenance product of choice.
Model |
Unit |
VC600 |
X-Axis travel |
mm |
600 |
Y-Axis travel |
mm |
410 |
Z-Axis travel |
mm |
510 |
Distance between spindle nose to work table surface |
mm |
125-635 |
Distance from spindle center to column guide |
mm |
220-630 |
Table size |
mm² |
800×400 |
Max.loading capacity |
kg |
500 |
Width of T-slot |
mm |
3×18H8 |
Max.speed of the spindle |
rpm |
8000 |
Spindle taper |
- |
BT-40 |
X/Y/Z-axis rapid speed |
m/min |
10/10/8 |
The maximum cutting feed rate |
m/min |
5 |
automatic tool changer |
|
Carousel Style Tool Bank |
tool storage capacity |
|
16 |
T-T Tool-changing |
sec |
7 |
Max.Length of tool |
mm |
350 |
Max.O.D.of tool(the neighbouring without tools) |
mm |
Φ90/Φ180 |
Max. tool weight. |
kg |
6 |
Spindle motor |
kw |
7.5/11 |
X/Y/Z motor |
kw |
11/11/16 |
Cooling pump motor |
w |
90 |
Positioning accuracy |
mm |
X/Z:0.016,Y:0.014 |
Positioning accuracy |
mm |
X/Z:0.01, Y:0.008 |
Machine overall dimensions(L×W×H) |
mm |
2200×2224×2396 |
Machine weight |
kg |
4000 |
power requirements |
kw |
150 |
A: You can choose FOB,CIF, DDU or other terms. You can book ship or I can book ship for you.
A: You can make the inquiry online on Alibaba, or send email to us. It is better if you can tell what is your detailed request information. We will reply to you within 2 hours on work days, and within 24 hours on holiday.
A: You can choose machine on our website accodring to your request. Or You can let our seller know what is your request specifcation or what is your parts, so let our seller recommend suitable machine to you. We have do trade machine years, and export machine to over 100 countries. We have CE, ISO, SGS and other quality certificate.
A: We can make the deal on Alibaba online platform, you can pay by T/T or Credit card. You can also pay to my company business bank account. You can also choose L/C or other way.
A: If the machine you will order is standard machine, we can ready the machine within 15days. If special machine, please confirm with our seller. The ship time is about 30 days to Europe, America. If you are from Australia, or Asia, it will be shorter. You can place order according to delivery time and ship time.
A: warranty is one year, but we will offer lifetime service for machine.
