Dependable Performance small cnc machine center price BVMC1370 For Sale
- 30 Set / Sets per Month
- shenzhen
- T/T Credit Card
- SMT panasonic CM202-DS
- vmc650 CNC machining center|CNC machining center 650
- vmc850 CNC machining center|Vertical Machining Center
- vmc650 CNC machining center|CNC machining center 650
- Plastic product processing flame-retardant ABS mold production Plastic shell Plastic accessories Injection molding mold design
- Manufacturer abs blow mold processing PP PE Injection mold construction processing large electronic product mold injection
Product Details
Condition: | New | Type: | Vertical | Brand Name: | XiaShi |
Model Number: | BVMC1370 | Voltage: | 380v/50Hz | Power(W): | 18KVA |
Dimension(L*W*H): | 2900*2700*3100mm | Weight: | 8500kg | Certification: | ISO |
Warranty: | 1years | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Dependable Performance small cnc machine center price BVMC1370 For Sale
DESCRIPTION
1)Casting is made by advanced nano Meehanite. Such material is very stable; It can make sure
there is no distortion after long term use. Main structure adopts ANSYS limited unit software
analysis, to reach highest and best rigid structure design.
2)We design strong structure to build column, avoid and reduce distortion while cutting.
3) Nut integrated design
Nut block for screw and main machine body are built together for every axis, with this design, machine will get better rigidity, and won't lost precision while heavy cutting and acceleration
movement impact
4)Adopt three slide blocks for single axis
Adopt three slide blocks for single axis will enhance load capacity around 30%, with this
method will improve the load capacity.
5)Optimized structure of heavy rail linear guide
Comparing with ball screw guide, its lead capacity and damping properties has been improved
30% and 15% respectively: Comparing with hard track guide, dynamic motion function has
been improved 300%, at the same condition, the machining efficiency will be 2%-15% better,
life of machine will be 36 times longer, so without shutting the machine down to repair, it will
save 5-20% precious time
6) High accuracy, high inflexible principal axis
Belt transmission type principal axis can provide biggest RPM800012000. Special designed
principal axis bear configuration, show us the outstanding rigidity of principal head. Precious
ball screw assembly is adopted for X, Y and Z axis, such screw is pre processed to ensure best precision and minimize the error.
7)Disc style ATC system
8). Advantage of system
1. MITSHBISHI choose 64bite high speed CPU and PLC as the heart if control system, not
only improve data processing speed, but also raise machining efficiency obviously.
2. Most advanced hardware is adopted, it is advantage to enhance the ability of high speed
processing and the ability of compensation,
3. System support various language and can be used worldwide.
4. Principal axis is connected by parallel bus.
Servo system
Swift response and stable location loop control system will be most beneficial while machining
process, it also realize stable control of speed up and speed down.
1. Adoption of the medium and small model servo motor and high-resolution decoder
2. Enhance the rigidity of machine tool
3. Special characteristics in stable control of speeding up and down
4. Reduce parts processing time and improve the machining precision of parts.
Parameters
CNC Vertical Machining Center | Unit | BVMC1370 |
X/Y/Z axis travel | mm | 1300x700x650 |
Table upper surface to spindle nose end face | mm | 150-800 |
Table to spindle nose | mm | 780 |
Positioning Accuracy (mm) | mm | ±0.005 |
Repeatability Accuracy (mm) | mm | ±0.003 |
Spindle Speed (rpm) | mm | 8000 |
Spindle bore taper |
| NO.50 |
Table dimension | mm | 1400x710 |
Max. load on table | kg | 1000 |
T shape groove | mm | 18TxP152x5 |
Power (X/Y/Z) | kw | 3.0,3.0,3.0 Mitsubishi 2.5,2.5,2.5 Fanuc |
Rapid speed (X/Y/Z) | mm/min | 24000 |
Cutting speed (X/Y/Z) | mm/min | 12000 |
Tool holder model |
| BT50 |
Tool capacity | pcs | 20/24 |
Tool exchange time(T-T/C-C) | sec | 3.5/7 |
Spindle power (30min/successive) | KW | 15/11 |
Rated Power | KVA | 30 |
Air power | Mpa/L/min | 0.6/200 |
Machine height | mm | 3200 |
Floor space | mm | 3600x2800 |
Machine Weight | Kg | 12000 |
Optional System
Japan Mitsubishi | Japan FANUC | Germen SIEMENS | Taiwan SYNTEC |
|
|
|
|
Optional Auto Tool Change (ATC System)
Umbrella Type | Arm Type(Disc Type) | ||
16pcs | 20pcs | 16pcs | 24pcs |
|
|
Optional 4th Axis
| CNC-201R | Hold Dia. 200mm | Taiwan |
CNC-251R | Hold Dia. 250mm | Taiwan | |
CNC-321R | Hold Dia. 320mm | Taiwan | |
TK13315E | Hold Dia. 315mm | China |
Optional Parts
Spindle Oil Cooler | Tool Presetter | Chip Convoyer |
|
|
|
Main Application
BMVMC series CNC vertical machining center is a cooperative designed product with German company. We adopted advanced international idea of designing a modern structure machine
tool and used the latest software to analyze various technical data. Most reliable and high
quality components and spare parts have been introduced to this nice machine tool. No matter
precise elements machining or moulds processing, BMVMC series machining center will offer
you excellent performance, high efficiency, higher accuracy and long-term stability.
Suitable for: machining parts of automobile, mold industry and so on.
Picture details
Why Choose us?
- We have our own factory and strong production capacity.
- we insist on good quality and have strict quality standards
- The hiring of experienced staff to guarantee high quality.
- Our product can be made as per your requirement .
- 24 hour online communication for you.
- We have more than 6 years of export experience.
FAQ
Q: What information should I let you know, if I want to get a product offer?
A: 1. the size of your work piece
2. the CNC system you preferred if you need CNC type
3. the work piece drawing if you have
Q: How to control the quality of production processes?
A: We have a professional quality inspectors to check on the quality of the finished product.
Q: Is it possible to visit your factory?
A: It is very convenient to visit us and all clients from around the world are highly welcomed.
Q: What’s the MOQ?
A: The MOQ is 1 set.
Q: What’s the quality assurance and service ?
A: We offer one year warranty and 100% quality inspection before shipment. We shall reply your message within 24 hours to solve your problem.
If you have any other requirements for the size,please do not hesitate to contact us,or you can advise us your ideas or thoughts for the machine,we can kindly design for you and communicate with you for the details.
