Help CenterProfessional Vertical CNC Engraving and Milling Machine
Related Products
-
Vertical CNC Engraving and Milling Machine With High Precision DX6060US$ 100 - 1,000MOQ: 1 Set -
Professional Cheap Price Cnc Metal Engraving Machine Price/cnc Router for Metal Cutting DX6080US$ 100 - 1,000MOQ: 1 Set
-
Chinese Cnc Machining Center Price Series THM/TGKUS$ 1,000 - 100,000MOQ: 1 Set
-
Factory High Precision Cnc Vertical Machining Center XH715DUS$ 1,000 - 50,000MOQ: 1 Set
-
CNC Large Size Precision Machining Center, Flexible Machine KHC100/KHC125/KHC140 /KHC160 /KHC200US$ 1,000 - 100,000MOQ: 1 Set
Specifications
cnc engraving machine small
Taiwan Three axes ball screw
Japan three axes servo motor
Imported linear way
cnc engraving machine small -Features:
1.L.M. guide-ways for all axes
2.Pre-Loaded ball screws for all axes
3.Centralized lubrication system
4.AC Servo Drive for all axes
5.Water cooled spindle
6.Electric hand control wheel
7.Air blast for spindle taper cleaning
8.Fully covered machine
9.Telescopic covers for all 3 axes
10.Auto & Manual coolant system
Optional:
1.Plug-in 4th and 5th axis
2.Chip Conveyor
3.Flood Coolant System
4.Voltage Stabilizer
5.Machine Lamp
cnc engraving machine small -Specification
Model |
5050 |
6060/6080 |
8080/80100 |
80120 |
Working Table size (mm) |
500×500 |
600×600-600×800 |
800×800-800×1000 |
800×1200 |
Stroke(X/Y/Z)(mm) |
500×500×240 |
600×600×300-600×800×300 |
800×800×300-800×1000×300 |
800×1200×300 |
Max.feeding speed |
8000 |
8000 |
8000 |
10000 |
Max.cutting speed |
6000 |
6000 |
6000 |
8000 |
Accuracy of couple knives |
0.002(Automatic) |
|||
Positioning Accuracy (mm) |
0.01/300 |
0.01/300 |
0.01/300 |
0.01/300 |
Duplicate positioning Accuracy (mm) |
0.005 |
0.005 |
0.005 |
0.005 |
X/Y verticality |
0.015/300 |
0.015/300 |
0.015/300 |
0.015/300 |
Diatance between working table and Main spindle(mm) |
60-300 |
150-450 |
20-420 |
80-380 |
type groove size(mm) |
5-12×100 |
5-14×150 |
5-14×150 |
5-14×250 |
Gantry height(mm) |
400 |
500 |
520 |
560 |
Gantry across height(mm) |
300 |
450 |
420 |
380 |
Gantry width(mm) |
600 |
700 |
900 |
900 |
Max. load on table(kg) |
200 |
300/400 |
500 |
600 |
Spindle speed(r/min) |
600-24000 |
600-18000 |
600-18000/15000 |
600/15000 |
Main motor power(kw) |
3.2 |
4/5.5 |
5.5/7.5 |
7.5 |
Weight(kg) |
2500 |
3000 |
3700 |
4200 |
clamping chuck |
ER20 |
ER25/32 |
ER32/40/BT30 |
ER32/40/BT30 |
System grade servo |
LNC/ Syntec/ Fagor-Yaskawa /Panasonic |
|||
Battery request(kva) |
10 |
13 |
15 |
16 |
Dimension(mm) |
2000×1800×2100 |
2400×2200×2300 |
2800×2500×2500 |
3000×2600×2500 |
