Home > Manufacturing & Processing Machinery > Casting & Forging > Cold Forging > Normal Large Heavy Duty Gear Hobbing Machcine for Sale Dia 1300/1600 Y31160k/Y31160A
Normal Large Heavy Duty Gear Hobbing Machcine for Sale Dia 1300/1600 Y31160k/Y31160A
US$ 5,000 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Gear
Production Capacity:
100%
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Large Process Capacity Gear Hobbing Machine Factory Y31200US$ 5,000 - 50,000MOQ: 1 Set -
Gear Hobbing Machine for Cylindrical Spur and Helical Gears, Worm Gears and Sprocket Y31630KUS$ 5,000 - 50,000MOQ: 1 Set
-
Gear Hobbing Machine for Large Work Pieces D800mm From China Gear Machine ManufacturerUS$ 5,000 - 50,000MOQ: 1 Set
-
Mini CNC Gear Shapping Machine Small Gear Shaper Machie Style YK5115US$ 10,000 - 50,000MOQ: 1 Set
-
TB-30NC Auto Feeding Thread Rolling Machine CNC Bolt Thread Rolling MachineUS$ 2,000 - 20,000MOQ: 1 Set
Condition
New
Application
Gear
Production Capacity
100%
Brand Name
XIASHI
Model Number
Y31160K
Power(W)
15KW
Dimension(L*W*H)
2450x1272x1790mm
Weight
17500kg
Certification
ISO 9001-2008, CE
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Item |
Y31160K |
Y31160A |
Max Work Piece Dia |
1300/1600mm |
1600mm |
Max Module |
16/20mm |
24mm |
Max Width of Teeth |
450mm |
1100mm |
Max Hob Dia/Length |
280/320mm |
325/360mm |
Dia of Work Table |
1100mm |
1450mm |
Speedle Speed/Steps |
19-124rpm/7 |
10-92rpm |
Max Hob Shift Axial |
100mm |
140mm |
Main Motor |
15kw/1500rpm |
22kw/1500rpm |
Taper of Hob Arbor Fitting |
Morse 6 |
Morse6 |
Distance Between Hob Axis And Worktable |
200-700mm |
680-1830mm |
Center Distance Between Hob And Work Table |
200-910mm |
100-1000mm |
|
Distance Between Tailstock End Face and Worktable Surface.
|
500-900mm |
985-1985mm |
Worktable Bore Diameter |
260mm |
260mm |
Max Hob Swiveling Angle |
±60° |
±45° |
Dia of Hob Arbors Dia |
32,40,50mm |
32,40,50,60,80 |
Load Capacity |
3.5t |
10T |
Overall Dimension (LXWXHmm) |
4380x2390x2500 |
7350X2850X4550 |
GW/NW(kgs) |
17500/16000 |
30000 |
