YP-S57 20kHz Ultrasonic Dispersion Machine
Product Description
Using liquid as medium, by ultrasonic cavitation in liquids, dispersion and reunite the particles in liquid, this process is called ultrasonic dispersion.
The comparison of different dispersion
| Method | Particle size | The number of particles | Effect |
| Grinding | > 10μm | *1010 | nonuniform |
| Comminution by Gas Stream | > 10μm | *1010 | nonuniform |
| Emitting Smoke Bomb | > 6μm | *1011 | nonuniform |
| Ultrasonic Dispersion | < 4μm | *1013 | uniform |
Sepecification
| Model | YP-S51 | YP-S53 | YP-S55 | YP-S57 | YP-S59 | YP-S61 |
| Frequency | 28 kHz | 20 kHz | 20 kHz | 20 kHz | 20 kHz | 20 kHz |
| Power | 1000 W | 500 W | 1000 W | 1500 W | 2000 W | 3000 W |
| Voltage | 220±10% V | |||||
| Temperature | 300 °C | |||||
| Pressure | 30 MPa | |||||
| Intensity of sound | ≥15 W/cm² | ≥10 W/cm² | ≥20 W/cm² | ≥30 W/cm² | ≥40 W/cm² | ≥60 W/cm² |
| Capacity | 400 L/H | 300 L/H | 600 L/H | 900 L/H | 1200 L/H | 1800 L/H |
| Genarator | V5.0 | V6.0 | V6.0 | V6.0 | V6.0 | V6.0 |
| Material of Horn | Titanium alloy | |||||
| Size | Generator: 200*420*280 mm Horn:Standard or Custom Made | Generator: 400*430*190 mm Horn:Standard or Custom Made | Generator: 400*430*190 mm Horn:Standard or Custom Made | Generator: 400*430*190 mm Horn:Standard or Custom Made | Generator: 400*430*190 mm Horn:Standard or Custom Made | Generator: 400*430*190 mm Horn:Standard or Custom Made |
Applications
| Liquid-Liquid | fuel with water, maquillage, food, waste water ,mineral oil, water-proofing additive and so on |
| Solid-Liquid | coating material, lubricant, drug, food, silica, ceramic raw material and so on |
| Gas-Liquid | oxygen water, carbonic acid compound and so on |
Advantages
- High-power:single set of maximum power can reach 3000W.
- Stable:24 hours of continuous work.
- Use the titanium alloy as the transducer and the horn material, improve the vibration transmission efficiency, the service life of the equipment is greatly improved.
- High temperature resistant:the horn can withstand 350℃.
- High pressure: the maximum pressure 30MPa.
- A plurality of the horn design: the effective increase of ultrasonic radiation area, the radiation effect is more uniform.
- Can be make scheme according to the special requirements of customers.
Why Choose Us?
- Hangzhou Success Ultrasonic Equipment Co.,Ltd is the leader of high-power ultrasonic equipment in China.
- Our company was founded in 1978.We have more than 30 years experiences.
- We have more than 20 engineers.They can make design scheme according to your requirements.
- Our piezoeletric ceramic disc is imported from Germany.The transducer have longer service life.
- Welcome to send us your sample.We have an open laboratory.It is free for making experiment.And we will take a video for you.
- We are specializing in high-power ultrasonic device and approved by CE, BV, ISO 9001.
After-Sales Service
- 24 hours technical supports and after-sales service
- Non-human damage, one year guaranteed exchange, three years warranty
