UDM Series Drilling And Milling Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
Used
Place of Origin:
Shandong, China
Brand Name:
EAGLE
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
Used
Place of Origin
Shandong, China
Brand Name
EAGLE
Model Number
UDM series Drilling And Milling Machine
Type
Universal
CNC or Not
Normal
Certification
CE
Specifications
UDM series Drilling And Milling MachineUDM series Drilling And Milling Machine
Universal milling/Drilling Machine
UDM 40110,mechanical feed on X axis
UDM 40110A,mechanical feeds on X,Y axes
UDM 40110B,automatic feeds on X,Y,Z axes
| Optional accessories: |
| Dividing head F11100 |
| Rotary table TS250 |
| Standard Accessories |
| Drill chuck |
| Mill chuck |
| wrench |
| Inner-haxagonal spanner |
| Wedge shifter |
| Reduction sleeve |
| Vertical draw bar |
| Horizontal draw bar |
| Horizontal milling bar |
| Milling bar |
| Spindle arbor |
| Operation manual |
| Quality certificate |
| Packing list |
| Model | UDM 40110 UDM 40110A UDM 40110B |
| Max.drilling dia. (MT4 taper) | 40 |
| Max.end milling width | 125 |
| Max.vertical drilling dia. | 25 |
| Max.tapping dia. | M16 |
| Spindle nose to table surface | 80-460 |
| Spindle speed range | 67-2010(V) 38-1310(H) |
| Spindle travel | 120 |
| Automatic spindle feeds | 0.1 0.15 0.3 |
| Table size | 1120×260 |
| Table travel | 600×300 |
| Overall dimensions | 1580×1450×2150 |
| Main motor power | 1.5/2.2 2.2 |
| N.W/G.W | 1350/1500 |
| Item No. | 141016 141017 141018 |
