UDM50110 Drilling And Milling Machine

UDM50110 Drilling And Milling Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
Used
Place of Origin:
Shandong, China
Brand Name:
EAGLE
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.
Condition Used
Place of Origin Shandong, China
Brand Name EAGLE
Model Number UDM50110 Drilling And Milling Machine
Type Universal
CNC or Not Normal
Certification CE

Specifications

UDM50110 Drilling And Milling Machine

UDM50110 Drilling And Milling Machine



Universal Drilling/Milling Machine
UDM 50110A:Automatic spindle feed.
UDM 50110B:Table feed in X,Y direction through gear drive.
UDM 50110C:Exchange with Taiwan milling head ,motorized lifting and lowering of table Z axis



Standard accessories
Drill chuck
Inner-haxagonal spanner
Wedge shifter
Reduction sleeve
Draw bar
Spindle Abor
wrench
Milling chuck
Horizontal milling abor
Operation manual
Quality certificate
Packing list



Optional accessories:
Dividing head F11100A
Rotary table TS250A
ModelUDM 50110UDM 50110AUDM 50110B
Max.drilling dia.(MT4 taper)(mm)505050
Max.end milling width(mm)10014(cast iron)100
Max.vertical milling dia.(mm)25/25
Max.tapping dia.M1625M16
Distance from spindle nose to table surface(mm)90-400100-430100-460
Spindle speed range(r.p.m)110-1760(V)
38-1310(H)
90-2000(V)
38-1310(H)
115-1750(V)
38-1310(H)
Spindle travel(mm)120120120
Table size(mm)1120×2801120X2601120×260
Table travel(mm)600×230600X300600×270
Overall dimensions(mm)1580×1330×22501520X1285X21501655×1450×2150
Main motor power(kw)0.85/1.5(V) 2.2(H)2.20.85/1.5(V) 2.2(H)
N.W/G.W(kg)1350/15001350/15001500/1600
Item No.141020141021141022
