Universal Swivel Head Milling Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
Eagle
Type:
Other, Universal, Universal
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Brand Name
Eagle
Type
Other, Universal, Universal
CNC or Not
Normal
Certification
CE
Specifications
Universal Swivel Head Milling MachineCE standard
Universal Swivel Head Milling Machine
| Universal Swivel Head Milling Machine | ||||
| -extra large work table and large travel ranges on all axes | ||||
| -sturdy and torsionally rigid construction | ||||
| -universal swivel head - cutter can be moved to any spatial angle | ||||
| -infinitely variable feed speed and rapid feed with servo motor and axis control on all 3 axes | ||||
| -preloaded ball screw - zero-backlash - preloaded for easy and precise feeds | ||||
| -simultaneous axis movement | ||||
| -Turcite-B coated guides | ||||
| -dovetail guideways on X-axis | ||||
| -square guides on Y and Z axis (only Z axis on the UWF 10) | ||||
| -hardened and ground gears, nitrated | ||||
| -swiveling control panel, fully equipped with all operating elements | ||||
| -automatic lubricant supply | ||||
| -spindle brakes | ||||
| -equipment according to CE | ||||
| Specification | Unit | UHM 400 | UHM 500 | UHM 500A |
| Setup area(LXW) | mm | 1235x400 | 1635x500 | 2000x500 |
| Number of T-slots | mm | 5 | 5 | 5 |
| T-slots width | mm | 18 | 18 | 18 |
| T-slots distance | mm | 80 | 80 | 80 |
| Table traverse, longitundinal x | mm | 900 | 1600 | 1500 |
| Table traverse, vertaical z | mm | 450 | 450 | 500 |
| Cross traverse (milling bar) y | mm | 650 | 650 | 650 |
| Head swivels | 360° | 360° | 360° | |
| Spindle mount | mm-1 | ISO40 | ISO50 | ISO50 |
| Spindle speeds | mm/min | (27)30-2050 | ISO50 | ISO50 |
| Feed, longit (infin.var.) | mm/min | 10-1000 | 10-1000 | 10-1000 |
| Feed, cross (infinite) | mm/min | 10-1000 | 10-1000 | 10-1000 |
| Feed, vertical (infinite) | mm/min | 6-640 | 5-550 | 5-550 |
| Rapid feed, longit. | mm/min | 2540 | 2200 | 2200 |
| Rapid feed, cross | mm/min | 2540 | 2200 | 2200 |
| Rapid feed, vertical | mm/min | 1700 | 1100 | 1100 |
| Spindle nose-table distance | mm | 50-500 | 80-530 | 80-530 |
| Throat | mm | 63-713 | 60-760 | 60-760 |
| Main motor rating | kw | 5.5 | 7.5 | 7.5 |
| Axis drive for each axis | DC Serve | DC Serve | DC Serve | |
| Max. table load capacity | kg | 800 | 1800 | 1800 |
| Dimensions (LXWXH) | mm | 1940x2220x2115 | 2140X2621X1940 | 2140x2986x1940 |
| Weight | kg | 3000 | 3400 | 5500 |
| Item No. | 131220 | 131222 | 131223 | |
| Standard accessories | ||||
| Position indicator | ||||
| Universal swivel heda | ||||
| Operating tools | ||||
| Automatic central lubrication | ||||
| Coolant system | ||||
| Operator manual | ||||
