Engine Lathe

Name: Engine Lathe
Brand: eagle
SKU: 140923846
Availability: InStock

Eagle Industries, Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Horizontal

CNC or Not:

Normal

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

CNC or Not Normal

Place of Origin Shandong, China

Brand Name eagle

Model Number LE6560

Specifications

1).CE standard
2).Max. swing over bed 600mm
3).Distance between centers 1000~2000mm
4).Removable gap

Bench lathe:E6560

Feature:

1,High speed precision lathe

2,Precision ground.

3,CE-conformity, electromagnetic brake can be amounted.

4,Safety torque limiting device for lead screw.

5,Safety overload clutch for feedrod.

6,Rapid traverse (optional).

7,Main spindle supported at 2 points with precision taper roller bearings.

Model	Unit	LE6560×1000	LE6560×1500	LE6560×2000
Max. swing over bed	mm	600
Max. swing over cross silde	mm	360
Max. swing over gap	mm	730
Effective length of gap	mm	260
Bed width	mm	330
Distance between centers	mm	1000	1500	2000
Spindle nose		ISO-C6 OR ISO-D6
Spindle bore	mm	65
Taper of spindle bore		Metric 70mm
Number of spindle speed		15
Range of spindle speed	r/min	22~1800
Range of longitudinal feeds	mm/rev	0.072~4.038
Range of cross feeds	mm/rev	0.036~2.019
Range of metric threads	mm	0.5~28
Range of inch threads	tpi	1~56
Diameter of tailstock sleeve	mm	65
Taper of tailstock bore		MT5
Travel of tailstock sleeve	mm	120
Power of motor	kw	7.5
N.W/G.W	kg	1640/2290	1870/2530	2130/2860
Overall dimensions (L×W×H)	mm	2420×1150×1800	2920×1150×1800	3460×1150×1800
Item NO.		115012	115013	115029

Standard accessories	Optional accessories
3-Jaw chuck(160mm)	Steady plates
Driving plate	Follow rest
Center & center sleeve	4-jaw chuck(200mm)
Tool box with tools	Face plate
Oil gun	Thread dial
Change gears set	Longitudinal automatic trip
	Live center
	Quick change toolpost
	Taper copy ruler
	4-position longitudinal automatic trip
