Mining Scraper Conveyor Accessories Scraper Conveyor Tail Drum

description

     Scraping machine tail roller, it includes baffle, set screw, sealing ring, bearings, bushings, cylinder body and shaft.

     Whose character is: close to the shaft axis, and at the end of the shaft axis neck, symmetrical equipped with shaft sleeve, bearing suits in the collar of peripheral;Near the shaft sleeve on the shaft journal, equipped with sealing ring, a transverse baffle, close to the cylinder body and bearing press on the sealing ring, a number greater than or equal to 1 set screws, become an organic whole repeatedly the baffle and the cylinder body.

     This machine tail roller bearing capacity big, impact resistance, simple structure, easy maintenance, can apply to water, dust and working environment, long service life and has great popularization value.

     The thickest drum of a diameter of 250 mm, 500 mm in length, single weighs 69 kg, this kind of roller structure is simple, easy to install.Prevent chain phenomenon.

detailed picture
