Rotary kiln belongs to building material equipment, which can be divided into cement kiln, metallurgy chemical kiln and lime kiln according to different materials. Cement kiln is used for making of cement clinker and there are dry and wet methods to make cement. Metallurgy chemical kiln is used for magnetic roasting of iron ore and oxidizing roasting of chrome and nickel in the steel factory; baking high-alumina mine in the refractory material factory; baking chamotte and alumina in the aluminium factory and baking chrome ore and chrome powder in the chemical plant. Lime kiln is used for baking active lime and dolomite in the steel factory and ferroalloy factory.
Rotary kiln is composed of cylinder, gears, support device, kiln liner and kiln tail sealing equipment, kiln head hood and combustion. Cylinder as heated pivoting part, made of high quality carbon steel plate, is supported on the support device by tire, and there is mechanical or hydraulic pressure catch wheel on the first or some gear in order to control the turning of cylinder. Because of the need of installation or maintenance, the bigger rotary kiln has auxiliary gears, which makes cylinder gyrate more slowly. To prevent cold air come in and dust overflow, the reliable kiln tail and head sealing equipment is installed on feed and discharge end.
Advantages
1. Hot Clinker Detection
2. Product Discharge Temperature
3. Product Entry Temperature
4. Mid-Zone Temperature
5. Combustion Gas Temperature
6. Kiln Shell Hot Spot Detection
For More Details Please do not hesitate to contact us via the following method
Email:china_george@126.com
Quick Lime, Cement Clinker Rotary Kiln
