Hot Air Circulation Drying Oven

Hot Air Circulation Drying Oven photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Hot Air Furnace
Place of Origin:
Henan, China
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao/ningbo/guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Hot Air Furnace
Place of Origin Henan, China
Brand Name saiye
Model Number SY-0
Power(W) 0.45kw
Dimension(L*W*H) 1500 * 1000 * 2044mm
Certification ISO9001
Warranty 1 YEAR
After-sales Service Provided Engineers available to service machinery overseas

Hot air circulation drying oven

Features:

Hot air circulation drying oven

Most of the hot air in the circulation, high thermal efficiency, save energy.

With forced ventilation function, adjustable wind distributing board is high in the oven, dry material evenly.Heat source can use steam, hot water, electricity, far infrared, choose widely.



The machine noise is small, running balance, temperature control, easy installation and maintenance.

Applicability is wide and can dry various materials, it is general in the drying equipment.

Scope of application:

Hot air circulation drying oven is suitable for pharmaceutical, chemical, food, agricultural and sideline products, aquatic products, light industry, heavy industry, such as unemployment materials and products heating curing, drying dehydration.Such as API, crude drugs, traditional Chinese medicine yinpian, water extract, powder, granule, granule, pill, packing bottle, pigment, dehydration vegetable, dried fruit and melons, banger, plastic resin, electric elements, drying varnish and so on.



Hot air circulation drying oven

The main technical parameters:



Model

Every time amount of drying

with
power

Steam
dosage

Up and down
Temperature difference °C

with
Baking plate

The dimensions

The wind amount

note

SY-0

25kg

0.45KW

5kg/h

Plus or minus 2

16

1500 * 1000 * 2044mm

3400m3/h

A single car

SY-I

100kg

0.45KW

18kg/h

Plus or minus 2

48

2300 * 1200 * 2300mm

3400m3/h

Two-door two cars

SY-II

200kg

0.9KW

36kg/h

Plus or minus 2

96

2300 * 2200 * 2300mm

6900m3/h

Double Four car door

SY-III

300kg

1.35KW

54kg/h

Plus or minus 2

144

2300 * 3220 * 2000mm

10350m3/h

Double Six car door

SY-IV

400kg

1.8KW

72kg/h

Plus or minus 2

192

4460 * 2200 * 2290mm

13800m3/h

Four eight cars





 Hot air circulation drying oven
