Specifications
SYXD-1600VTF Vertical Vacuum Tube stove1.Heating rate:0-10
2.Standard working temperature:1500C
SYXD-1600VTF Vertical Vacuum Tube stove
XD1600VTF Vertical Vacuum Tube Furnace is vertical tube furnace with 6" diameter one end closed alumina tube and stainless steel flange / ball valve. It is designed for processing advanced material up to 1600oC. The Precision digital temperature controller with 51 segments programmable is built in the furnace with +/- 1oC accuracy
Tchnical parameter:
Inside chamber Size |
13" Diameter x 10 " high |
|
Alumina Tube Size
|
One end closed alumina tube with purity .99.8% · Outside Diameter: 150mm · Inside Diameter: 140mm · Length: 600mm |
Max. Working Temperature |
1600°C |
Standard working temperature |
1500°C |
Temperature Control |
30 segments programmable and PID auto control |
Vacuum Flange |
· Stainless steel with double hi-temperature silicone O-rings ( <300oC) · Ball valve and vacuum gauge is installed for immediate use · Vacuum pressure up to 10Pa by mechanical pump · One porous ceramic disk is included. Must put the refractory disk in front flange to avoid flange over-heated |
Heating rate |
0~10 oC / min (suggestion at =< 5 oC) |
Temperature accuracy |
± 1°C |
Heating Element |
1800 Type MoSi2 Heating Element |
Working Voltage |
AC 220V 50HZ |
Max. Power |
9.5KW |
Net Weight |
180kg |
