SYXD-1400S lab use Muffle Furnace 0086-18638277628

FOB Price

USD $3,000 - $8,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other, Muffle Furnace
Usage	Heat Treatment Furnace	Place of Origin	Henan, China
Brand Name	SAIYE	Model Number	SYXD-1400S
Voltage	220V, 220V	Power(W)	10000
Dimension(LWH)	6507001000mm	Weight	230kg
Certification	ISO9001	After-sales Service Provided	Engineers available to service machinery overseas

SYXD-1400S lab use Muffle Furnace

Applications

1. Gravimetric analysis

2. Sintering

3. Quantitative analysis

4. Heat treating

5. Glass preparation

Product Description

1. Operation Temperature: 1100.C ( 1200.C Max for short time).

2. Maximum energy efficiency is achieved by surrounding the chamber with thermal-efficient alumina fiber ceramic insulation.

3. Three sides resistance wire coil for fast and uniform heating.

4. Heavy duty double layer structure with cooling fan. Lower teperature in outside case.

5. 0.5" diameter observation window made of quartz galss allow user to see insider chamber during heating operation.

6. K type thermocouple installed for immediate use.

7. Temperature controll unit can be separated from furnace , and make moving at easy.

8. PID automatic control via current limiting phase angle fired the resistor , e.g. SCR ( Silicon Controlled Rectifier)

9. Power control with 30 segments programmable.

10. Vent port installed on the top for gas flow. ( gas outlet)

Techncial parameter:

Chamber size	200x200x200mm(WHD)
Max.Temperature	1200C
Working temperature	1100C
Temperature accuracy	+ 1.C
Temperature controller	30 segments programmable and auto
Control Heating elements	Ni-Cr wire
Voltage	220V 50HZ, single phase
Power	4kw
