SYXD-1600MT heating Tube stove
SYXD1600MT tube furnace is a precision benchtop furnace using quality ceramic MoSi2 rods as heating elements. It is widely used for materials or chemical lab to sinter all types of new materials samples under vacuum or other gases condition. It is controlled by high precision SCR ( Silicon Controlled Rectifier) digital controller with accuracy +/-1.C and 30 segments programmable up to 1600.C.
Technical parameter:
Inside Chamber Size | dia60x300mm(diameter2.5" x 12") |
Standard Working Temperature | 1600.C ( continuous ) |
Maximum Working Temperature | 1650.C ( < 3 hrs) |
Temperature Control | 30 steps programmable and PID automatic control |
Heating Rate | 0~10.C / min (suggestion: =< 10.C) |
Temperature Accuracy | + 1.C |
Heating Element | MoSi2 heating elements |
Working Voltage | AC 220V Single Phase 60/50 Hz (or according to your requirement) |
Max. Power | 5 KW |
Net Weight | 150 Kg |
Note: The furnace tube is High purity Al2O3 ceramic
Dia60mm means outer diameter, inner diameter is about 52mm
300mm means the length of hot zone
Total length is 1000mm
Standard Sizes:
Model | Chamber size | Max. Temperature |
XD-1600MT | Dia40x300mm (1.5"x12") | 1600.C |
XD-1600MT | Dia40x450mm (1.5"x18") | 1600.C |
XD-1600MT | Dia60x300mm (2.5"x12") | 1600.C |
XD-1600MT | Dia60x450mm (2.5"x18") | 1600.C |
XD-1600MT | Dia80x300mm (3.0"x12") | 1600.C |
XD-1600MT | Dia80x450mm (3.0"x18") | 1600.C |
XD-1600MT | Dia100x450mm (4.0"x18") | 1600.C |
