Professional copper expanded metal machine with CE certificate
♣Product Description
copper expanded metal machine adopts mature technologies of the past as well as new technology ,such as full-automatic lubricating, NC stepping motor feeding, etc. It has good effect, control ability, stability and safety has been greatly increased. It has reasonable structure, elegant appearance. energy saving.
Suitable material : low carbon steel sheet, aluminium sheet, stainless steel sheet, aluminium magnesium alloy sheet, copper sheet, Nickel sheet.
♣copper expanded metal machinemain parameter
(1) 6.3 copper expanded metal machine
No | Type | JQ25-6.3 |
1 | Material Thickness | Max1.0 |
2 | Net Width | Max 600 |
3 | Punching Speed | 300 |
4 | Feeding Distance | 0-10 |
5 | Length of Mesh | Max20 |
6 | Motor Power | 2.2 |
7 | Weight | 0.95 |
8 | Dimension | 950*570*1780 |
(2) 16T copper expanded metal machine
No | Type | JQ25-16 |
1 | Material Thickness | Max1.0 |
2 | Net Width | Max 1000 |
3 | Punching Speed | 160 |
4 | Feeding Distance | 0-10 |
5 | Length of Mesh | Max30 |
6 | Motor Power | 3.0 |
7 | Weight | 2.0 |
8 | Dimension | 1800*1320*1550 |
(3) 25 copper expanded metal machine
No | Type | JQ25-25 |
1 | Material Thickness | Max1.5 |
2 | Net Width | Max 1000 |
3 | Punching Speed | 160 |
4 | Feeding Distance | 0-10 |
5 | Length of Mesh | Max40 |
6 | Motor Power | 4.0 |
7 | Weight | 3.0 |
8 | Dimension | 1940*1600*2010 |
(4) 40T copper expanded metal machine
No | Type | JQ25-40 |
1 | Material Thickness | Max2.5 |
2 | Net Width | Max 1500 |
3 | Punching Speed | 80 |
4 | Feeding Distance | 0-10 |
5 | Length of Mesh | Max80 |
6 | Motor Power | 11 |
7 | Weight | 6 |
8 | Dimension | 2870*990*2140 |
(5) 63T copper expanded metal machine
No | Type | JQ25-63 |
1 | Material Thickness | Max4.0 |
2 | Net Width | Max 2000 |
3 | Punching Speed | 67 |
4 | Feeding Distance | 0-20 |
5 | Length of Mesh | Max 200 |
6 | Motor Power | 11 |
7 | Weight | 10 |
8 | Dimension | 2400*3500*2300 |
(6) 100T copper expanded metal machine
No | Type | JQ25-100 |
1 | Material Thickness | Max6.0 |
2 | Net Width | Max 2500 |
3 | Punching Speed | 55 |
4 | Feeding Distance | 0-20 |
5 | Length of Mesh | Max 200 |
6 | Motor Power | 15 |
7 | Weight | 12 |
8 | Dimension | 3600*2500*3000 |
1.The spare parts and control cabinet will be loaded in wooden box.
2.The main machine is nude packing or plastic packing.
3.Also can do as customer's request.
1.If the buyer need,we can send our technical staff to the buyers factory to install the machine and providing the training in 30 days after the machines arrived the destination pory
2.Maintenance period:One year for whole machine except vulnerable parts
3.The number of technical persons :one technician per machine
4.The fees:the buyer have to pay the technical salary 100 USD per day,and the round-trip tiket,accommodation and other related fees
During the maintenance period.if the parts are broken caused by the product problem.seller will offer the parts for free,if you need we assign the tachicians to your factory ,then you will pay some related fees.
If you have any problem ,let me know,will help you try my best.
