Strong Power JM354 BackhoeTractor

Hubei Fotma Machinery Co., Ltd. Gold Verified Supplier
5Yrs
Strong Power JM354 BackhoeTractor thumbnail-1
Strong Power JM354 BackhoeTractor photo-1
US$ 3,000 - 15,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 25.9kw
Certificate EPA
Brand Name JM
Model Number 354
After-sales Service Provided Overseas third-party support available

Specifications

Strong Power JM354 Backhoe tractor
High quality and reasonable price;
Excellent performance;
better service;
easy control.

Strong Power JM354 backhoeTractor  is the most popular Chinese tractors for export. Jinma brand compact tractors were designed for small agricultural farms and is suitable for stables, orchards, vineyards, landscape and much more.  The  former Jinma compact tractors are available in 20 to 75 hp  two wheel and four wheel drive, and now its supply range expend to 125hp.  It is a line of compact tractors that offers a large drive force and low fuel consumption, at an considerable low cost.


.
  Strong Power JM354 backhoeTractor includes: electrical cluster gauge, heavy duty switches  for headlights, tail lights, combined signal lights etc.,  full lift hood gives easy access to engine and battery compartment, new style wrap around headlights,  rear dual hydraulic hook-ups,  stylish  heavy duty round fiberglass fenders and EPA approved engines.

Specification
Tractor parameters
Model
JM354
Drive type
4WD
Overall dimensions( L*W*H )

3230*1435*1985
Wheel track(mm)
  front
1200
  rear
1150-1450
Wheel bass(mm)
1833.5
Ground clearance(mm)
292
Rated traction force(N)
8800
Construction mass(kg)
1800
Min.turning radius(m)
4.2
Engine
Model
3cylinder
Type
3cylinder engine,
 water cooled
Rated power(km/hp)
25.7/35
Rated speed(rpm)
2350
Drive system
Clutch
Dual-stage
Gear box
(4+1)*2
Main drive
one pair of spiral bevel gearing
Differential
Bevel gear
Differential lock
Jaw lock
Final transmission
Spur gear,
 external gearing
Traveling mechanism
Type
   front
7.5-16
   rear
11.2-24
Steering gear
Hydraulic(power) steering
Brake
Disc type
Working device
Hydraulic system
Lifting capacity at 610mm(N)
5800
3-point suspension
Category:1
Gear pump flow
20L/Min
P.T.O  shaft
Rotating speed(rpm)
540/720 or 540/1000
Spline size
6 @ 35 Rectangular spline




 Strong Power JM354 BackhoeTractor







Strong Power JM354 BackhoeTractor



 Strong Power JM354 BackhoeTractor







Our products are reliable,if you have any questions, please don't hesitate to contact us.And if you play an larger order, we will give you a discount. We also hope to do more future business with you.
