JM164Y 16hp jinma tractor

Name: JM164Y 16hp jinma tractor
Brand: Jinma
Price: USD $3,000 - 150,000 / Unit

FOB Price

USD $3,000 - $150,000 / Unit

1 Unit(Min.Order)

Supply Ability 500 Unit / Units per Month
Port Shanghai
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Type:	Wheel Tractor	By wheel:	4WD
Usage:	Garden Tractor	Drive Type:	Other, Gear Drive, 4WD	Power(W):	11.8KW
Certificate:	EEC	Brand Name:	Jinma	Model Number:	JM164Y
After-sales Service Provided:	Overseas third-party support available

Packaging Details

iron crate or tractor

Product Description

Specifications

JM164Y 16hp jinma tractor
Low noise; Low emission;
Powerful engine;
Convenient control;
High quality with reasonable price ;

JM164Y 16hp jinma tractor

The tractors are suitable for garden applications, hobby applications,wet&dry land applications,transportation in plain or hilly areas.The tractors are further enhanced by the offering of a complete range of matching implements like loaders, backhoe, post hole digger, scaper,leveler,rotavator,tiller,cultivator,plough, harrow,wood chipper,mower,snow blower,and etc.

Specification of JM164Y 16hp jinma tractor

Tractor Parameters	Model		JM-164
	Drive Type		4WD
	Overall Dimensions LWH(mm):		20559451050
	Wheel Track (mm)	Front	800
		Rear	740,840,940
	Wheel Bass(mm)		1280
	Ground Clearance (mm)		250
	Rated Traction Force(N)		3900
	Construction Mass(kg)		552
	Min.Turning Radius(m)		2.30
	Theoretical Speed (km/h)	Forward	1.32,1.95,3.04,6.01,8.9,13.92
		Reverse	1.63,7.46
Engine Specifications	Model		3M78
	Type		3-Cylinder Vertical,water cooled,4 stroke cycle
	Rated Power(kw/hp)		11.8/16
	Rated Speed (rpm)		2300
	Bore*Stroke (mm)		75*77.6
	Total Displacement(L)		1.028
Drive System	Clutch		7'Single Stage
	Gear Box		(3+1)*2
	Main Drive		Columniform gear
	Differential		Bevel Gear
	Differential Lock		Jaw Lock
	Final Transmission		Spur Gear, External gearing
Traveling Mechanism	Tyre	Front	5.00-12
		Rear	7.5-16
	Steering Gear		Power Steering
	Brake		Disc type
Working Device	Hydraulic System	Lifting Capacity at 610mm Behind Lift Point (N)	2280
		3-Point Suspension	Category:0
	P.T.O Shaft	Rotating Speed (rpm)	540/720/1000
		Spline Size	6-35 Rectangular Spline
OPTIONS			ROLL BAR,CANOPY,HYDRAULIC STEERING

Factory show for jinma tractors

If you want to know more information,please send us Email.

Company Profile

Hubei Fotma Machinery Co., Ltd.

Hubei Fotma Machinery Co., Ltd. is a professional manufacturer and supplier of industrial products especially in the field of farm machinery and construction equipment.

Our annual turnover is over 20 million US dollars. We have highly qualified staff, including both senior employees who have more than 20 years' import/export experience and new employees who have just graduated from foreign trade colleges.

"Quality First, Price Best, Service Foremost" is our business principle. We can also process the goods according to your individual needs. Featuring high quality standards, rigorous management measures and advanced technology, we have built up a fine reputation among both domestic and overseas customers.

We have traded in over 100 countries in the world. We will be glad to work with worldwide new partners.

Contact Us

Hubei Fotma Machinery Co., Ltd.: Contact nameLi Liu; Phone86-27-67845266; AddressBuilding 3, International Enterprises Center, 2 Te 1# Guanshan Road, Wuchang, Wuhan City, Hubei Province. China Wuhan,Hubei
