Specifications
JM204 tractor jinmaPowerful engine;Full hydraulic
Convenient control
High quality with reasonable price
Competitive price
JM204 tractor jinma
Specification
Tractor Parameters | Model | JM-204 | ||
Drive Type | 4WD | |||
Overall Dimensions L*W*H(mm): | 3080*1280*1930 | |||
Wheel Track (mm) | Front | 1000,1100 | ||
Rear | 1040~1200 | |||
Wheel Base(mm) | 1645 | |||
Ground Clearance (mm) | 295 | |||
Rated Traction Force(N) | 4800 | |||
Construction Mass(kg) | 1120 | |||
Min.Turning Radius(m) | 2.5 | |||
Theoretical Speed(Without creeper) ( km/h) | Forward | 1.73,2.64,4.14,5.71,8.01,12.20,19.14,26.40 | ||
Reverse | 2.28,11.02 | |||
Engine Specifications | Model | LL380BT | ||
Type | 3-Cylinder Vertical, water cooled,4 stroke cycle | |||
Rated Power (kw/hp) | 14.7/20 | |||
Rated Speed (rpm) | 2400 | |||
Bore x Stroke (mm) | 80*90 | |||
Total Displacement (L) | 1.357 | |||
Drive System | Clutch | Dual-Stage | ||
Gear Box | (4+1)*2 | |||
Main Drive | One Pair of Spiral Bevel Gearing | |||
Differential | Bevel Gear | |||
Differential Lock | Jaw Lock | |||
Final Transmission | External gearing, Spur Gear | |||
Traveling Mechanism | Tire | Front | 6.00-12 | |
Rear | 8.3-24 | |||
Steering Gear | Mechanical Steering | |||
Brake | Shoe type | |||
Working Device | Hydraulic System | Lifting Capacity at 610mm Behind Lift Point (N) | 3600 | |
3-Point Suspension | Category: I | |||
P.T.O Shaft | Speed (rpm) | 540/1000 | ||
Spline Size | 6 @ 35 Rectangular Spline | |||
Photo:
If you are interested in above tractor model or more details of other tractor models, please do not hesitate to contact us.
