Bulldozer SD16H Shantui

Name: Bulldozer SD16H Shantui
Brand: Shantui
SKU: 140838352
Availability: InStock

Hubei Fotma Machinery Co., Ltd. Gold Verified Supplier

5Yrs

US$ 10,000 - 100,000 MOQ: 1 Unit

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Shantui

Model Number:

SD16H

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Shantui

Model Number SD16H

Condition New

Moving Type Crawler Bulldozer

Machine Weight 17.5t

Dimension(Long * Breadth * High) 5345*3388*3032mm

After-sales Service Provided Overseas service center available

Specifications

Bulldozer SD16H shantui
Hgih quality with reaonable price
Excellent performance
Good aftersales service
Certificate:ISO

Bulldozer SD16H shantui

Introduce:

Specification:

ITEM	UNIT	SD16F
LWH (Ripper not included)	mm	534533883032
Operating weight (Ripper not included)	t	17.5
Engine	-	Shangchai SC11CB184G2B1/ Weichai WD10G178E25
Rated power	kW/rpm	120/1850
Gradeability	'	30
Blade type	-	Straight tilt blade U blade Angle blade
Blade width	mm	Straight tilt blade 33881149 U blade 35561120 Angle blade 3970*1040
Dozing capacity	m³	Straight tilt blade 4.5 U blade 5 Angle blade 4.3
Ma* drop below ground of blade	mm	540
Lift height of blade	mm	1095
Ripper type	-	Three-shank ripper
Ripping depth of ripper	mm	572
Lifting height of ripper	mm	592
Number of carriers (each side)	-	2
Number of track rollers (each side)	-	7
Number of track shoes (each side)	-	39
Width of track shoe	mm	560
Track gauge	mm	1880
Ground length and ground pressure	mm/MPa	2635-0.062
Pitch	mm	203.2
Forward speed	km/h	0-3.29
		0-5.82
		0-9.63
Reverse speed	km/h	0-4.28
		0-7.59
		0-12.53
