Specifications
1.Less fuel consumption2.Large power reserve
3. Hydraulic reel movement
4LZC-3.5 Rice Combine Harvester
Technical Features
1. Mature power match, less fuel consumption, good reliability and large power reserve.
2. Hydraulic reel movement, applicable to multiple crops.
3. With widened crawler, the ground pressure is less than 20Mpa and the pass ability in rice field is improved.
4. HST stepless speed regulating technology is adopted for more convenient operation.
5. With tangential flow and transverse flow double spike tooth type threshing drum, it can thresh more thoroughly.
6. The adjustable reciprocating type double vibrating screen is adopted, and the screening effect is better.
7. Advanced scientific design and diversified protection device contribute to more convenient service and maintenance.
8. Internationally advanced suspended supporting wheel design is adopted, which effectively prolongs the service life of chassis system.
Specifications
Model | 4LZ-2.0 | 4LZ-2.0Z | 4LZ-3.5 |
Threshing Type | Tangential+Axial | Single Vertical | Double Axial |
Engine Power/Speed KW/r | 55/2600 | 60/2800 | 66.2/2300 |
Overall Dimensions(L×W×H) | 4735×2320×2850 | 4970×3040×2520 | 5480×3220×2960 |
Operation Weight kg | 2565 | 2860 | 3880 |
Cutting Width mm | 2000 | 2000 | 2900 |
Feed Capacity kg/s | 2 | 2 | 3.5 |
Min. Ground Clearance mm | 240 | 255 | 265 |
Theoretical Operating Speed KM/h | Low speed 0-2.88/High speed0-4.54 | Low speed 0-4.68/Standard 0-6.3/Travel 0-9.72 | Low speed 1.19/Medium speed2.09/High speed/3.38 |
Transmission | Mechanical+stepless speed regulating | Mechanical+stepless speed regulating | Mechanical |
Re-threshing device | Spiral blade type | Plate | Re-threshing |
Threshing drum | Spike | Spike | Plate |
Grain unloading | Manual+Mechanical | Manual+Mechanical | Manual+Mechanical |
If there is any question, please send me Email to fotmasale01# or fotmasale01#. Please change # to @ when sending the Email.
