Specifications
1) Capacity is large2) Standard parts, reliable running
3) Low operating cost
Rubber Belt conveyor application scope:
The rubber belt conveyor is widely used in such industries as of metallurgy, mining, coal, harbor,
power station, buildingmaterials, chemical engineering,light industry,petroleum,grains,heating etc
Rubber belt conveyor feature:
As a closed conveying system, rubber belt conveyor provides for dust free transpot of material
with no contamination of surrounding environmenr.Rubber belt conveyor are ideal solution to
meet uniquereqirements of site geometry.They overcome inclines of 30 or more and can handle
almostany reasonale vertical and horizontal curve with ease.They can be easily adapted to the
suitation at a given site and allow optimum solution,even on extremely restrictive spaces.
Rubber belt conveyor technical parameter:
|
Belt Width (mm) |
Belt Length(m) / Power(kw) |
Belt Speed (m/s) |
Capacity (t/h) |
||
B400 |
≤12/1.5 |
12-20/2.2 |
20-25/3 |
0.8-2 |
40-80 |
B500 |
≤12/3 |
12-20/4 |
20-30/5.5 |
0.8-2 |
78-191 |
B650 |
≤12/4 |
12-20/5.5 |
20-30/7.5 |
0.8-2 |
131-323 |
B800 |
≤10/4 |
10-15/5.5 |
15-25/7.5 |
1.0-2 |
278-546 |
B1000 |
≤10/5.5 |
10-20/7.5 |
20-25/11 |
1.0-2 |
435-853 |
B1200 |
≤10/7.5 |
10-20/11 |
20-25/15 |
1.0-2 |
655-1284 |
Some notes in use Rubber belt conveyor:
1) The temperature of conveyed material should preferably be below 8°C
2)The operating ambient temperature should be within- 25C~+40°
and necessary protective measures should be taken for working environment with
special requirements.
Rubber belt conveyor images:
