Applications of Easy Jigger:
Easy Jigger belongs to a type of energy-saving gravity separation equipment, which is developed according to the law of layer theory of jigger bed stratification, and on the basis of traditional jigger. The performance of Easy Jigger has reached the domestic advanced level, and is one of the ideal devices in energy-saving gravity separation. When processing the open-pit mines, the Easy Jigger is a key machine with the principle of gravity separation. Easy Jigger pulse curve is like saw-tooth waveform to make rising water faster than the dropping water; enhanced the loose of bed, eased the inhaled role, so that heavy particles in the mineral can fully settlement, greatly improving the sorting capacity and recovery rate of equipment.
Working Principle of Easy Jigger:
Easy Jigger are intended for gravity separation by method of jigging. Easy Jigger are used for preparation of coals, ores of ferrous and non-ferrous metals with high efficiency of separation. Easy Jigger are equipped with modern system of pneumatic drive due to which efficiency of separation is essentially improved. Control system of Easy Jigger is intended for automatic control by process of jigging ensuring possibility of integration in control system of upper level with access to all technological parameters.
Features of Easy Jigger:
High capacity, Highconcentration ratio and high recovery
Fabricated with highest quality material
Easy to install, operate and maintain
Water conservation ,Saving water 30-40% than ordinary jig
The pulsation speed very easy adjusted by regulator
Suitable for roughing and desliming
Parameter of Easy Jigger:
Model |
Area jig |
Stroke |
Stroke |
Feed size |
Hutch |
Pressure |
Capacity |
Power |
Overall |
Weight |
JT0.57-1 |
0.57 |
8.5-12 |
60-160 |
< 6 |
1-2 |
≥ 0.3 |
1-2.5 |
1.5 |
1560×820 |
0.612 |
JT1-1 |
1.04 |
8.5-12 |
60-160 |
< 10 |
2-3 |
≥ 0.3 |
4-10 |
2.2 |
1322×1190 |
0.9 |
JT2-2 |
2.28 |
8.5-12 |
60-160 |
< 10 |
2-4 |
≥ 0.3 |
8-15 |
3 |
3225×1550 |
1.637 |
JT3-1 |
3.3 |
10-47 |
80-110 |
< 20 |
3-6 |
≥ 0.1 |
10-15 |
5.5 |
2662×2000 |
3.26 |
JT4-2 |
4 |
7-30 |
50-125 |
< 10 |
4-8 |
≥ 0.1 |
8-16 |
7.5 |
4240×1990 |
4.6 |
JT4-2A |
4 |
7-30 |
50-125 |
< 10 |
4-8 |
≥ 0.1 |
8-16 |
4 |
4240×1990 |
4.6 |
JT5-2 |
4.86 |
15-25 |
80-120 |
< 10 |
4-10 |
≥ 0.1 |
10-20 |
7.5 |
3940×2006 |
4.8 |
Gongyi Huashengming Heavy Machinery Factory are mainly produce crushing and mining equipment.
We have 20 years experience.Our products got ISO CE BV SGS certificate. If your are interested in any of our machine, pls feel free to contact us.
We will work with you to create a win-win situation, together to create the world famous brand of china.
Packing:
1.Rustproof and moisture proof before delivery.
2.Free fumigation plywood case for single machine,larger parts are wrapped by plastic sheeting.
3.Export standard container 20GP,40GP,40HQ,etc. for production line.
4.Other packaging according to your special requirement.
Shipping:
We usually accept EXW, FOB and CIF etc. terms.
1.By sea or by train. we have 20 years cooperate transport company. bestfreight, fast delivery.
2.Send B/L in 3-5 days after ship leaving.
3.will remind you before ship arrival.
1.Design most suitbale flow chart and layout freely according to your request.
2.Provide operating instruction and relative drawing.
3.We can send 1-2 technicians to the site for guiding the installation and commissioning.
4.We offer training service for free.
5.We offer the components with favorable price.
6.Lifetime Warranty.
1. Q: Can I visit your factory?
A: Yes. Many domestic and overseas customers visited our factory every year.
2. Q: What about the warranty of your equipment? Do you supply spare parts?
A: Our warranty is 2 years(24 months), and we can supply spare parts also.
3. Q: Do you provide after-sales service?
A: Yes. We have a professional after-sale service team to promptly and thoroughly solve your problems.
4. Q: Do you provide equipment operation training?
A: Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training. All of our engineers have passport.
5. Q: Do you provide producution flow chart?
A: Yes. Our experienced engineers are specialized in designing process flow for stone crushing plant and various ores beneficiation line.
6. Q: Can you test our sample raw material?
A: Yes. You can send your samples to us for testing and analysis.
7. Q: Have you made the whole stone crushing line?
A: Yes. We have made many large&small scale stone crushing line at home and abroad.
PAYMENT:
1.Accept T/T, L/C, Western Union, Money Gram or others payment terms.
2.20-30% in advance as down payment, the balance to be paid before delivery. We take pictures and testing videos of finished products before you pay the balance.
INSTALLATION:
If required, one or more engineer/engineers will be sent to guide the installation and commissioning of machines; the buyer shall prepare the materials and tools needed,and offer necessary assistance.The actual expenses include accommodation, meal and traveling fee of the engineer,and insurance also should be paid by the buyer. Every engineer should be paid 100 USD per day.
WARRANTY:
100% brand new when leaving the factory. The seller guarantee the quality of the machine (excluding wearing parts) for a period of one year from the date of trial run but not exceed 15 months from the date on which machine shipped out of the factory.
BANK DETAILS:
Beneficiary’s Bank Name: AGRICULTURAL BANK OF CHINA, HENAN, ZHENGZHOU BR.
Address: NO.50 LONGHAI ROAD ZHENGZHOU, HENAN, 450006 CHINA
SWIFT BIC:ABOCCNBJ160
Beneficiary Name: GONG YI CITY HUA SHENG MING HEAVY INDUSTRY MACHINERY FACTORY
Account No: 16-021314040001166
Why HSM Jigger Machine is popular in the world ?
The reason:The outstanding features of hammer crusher from HSM.
1.Easy to transport
2.Greatly reduce material transportation cost
3.Wide applications
4.Reliable performance and convenient maintenance
5.Customized production and flexible configuration
HSM insists on providing clients with overall solutions from equipment recommendation to debugging and installation, worker training, technical support and maintenance.
