Dongfeng 4*2 telescopic bucket truck for sale
Main technical parameters:
Vehicle model |
CLW5040JGKZ3 |
|
Type |
High altitude operation truck |
|
Overall dimensions(mm) |
7400×1980×3110 |
|
Gross vehicle gross(kgs) |
4325 |
|
Working Cage |
Internal size(mm) |
1100×600×1100 |
Rated loading(kg) |
200(or 2 persons) |
|
Max. Working height(mm) |
20000 |
|
Max. Height from ground(mm) |
12300 |
|
Max. Working radius(mm) |
7050 |
|
Working radius when doing the highest height(mm) |
2990 |
|
Working Boom |
Max. Raising angle of lower boom(º) |
70 |
Max. Raising angle of upper boom(º) |
70 |
|
Max. Raising angle of jib(º) |
90 |
|
Boom rack rotation angle(º) |
360 |
|
Outrigger |
Vertical span(mm) |
2950 |
Horizontal span(mm) |
2750 |
|
Travelling of vertical outrigger(mm) |
450 |
|
Adjustment |
Single adjustable |
|
Lifting |
Rated lifting weight(kg) |
995 |
Rated lifting height(mm) |
7700 |
|
Remarks:
The above information is just for your reference. We can manufacture the trucks as per your request and we can fulfill all your demands.
Should you have any other questions or need any other information, pls feel free to contact me. It would be my great pleasure to be on your service. Pls check my contact information as following:
Reference Picture:
