Foton 14m Mobile Platform Truck,aerial Operation Vehicle

Chengli Special Automobile Co., Ltd.

US$ 17,999 - 39,999 MOQ: 1 Set

Key Specifications

Transmission Type:

Manual

Condition:

New

Emission Standard:

Euro 2

Payment & Shipping

Payment Methods:

Port of Shipment:

Any port of China

Delivery Detail:

Delivery time depends on order quantity.

Transmission Type Manual

Condition New

Emission Standard Euro 2

Fuel Type Diesel

Dimensions (L x W x H) (mm) 6600*1900*2850

Place of Origin Hubei, China

Brand Name CLW

Model Number CLW5052JGKC-2

Specifications

Foton 14m mobile platform truck
With 3C
Passed the ISO9001-2000
Any quetions can contact me
OEM

Foton 14m mobile platform truck

Item		unit	parameter
Vehicle model			CLW5052JGKC-2 High-altitude Operation Truck
Chassis model			BJ1059VCAD6-2
Overall dimensions		mm	6600x1900x2850
	Factual loading	kg	200
	GVW	kg	Appro×4495
	Rated loading capacity		Appro×160
	Mass in working order		Appro×4000
	Body internal dimensions	mm	3370×1800×400
	Wheel base		3360
	F/R track base		1380/1458
	Approach/departure angle	°	19/15
Exhaust/hp		ml/kw	3707/70
Max speed		km/h	95
Tire specification		7.00R15,6.50-16	Engine type	BJ1059VCAD6-2
Traction system		4×2	transmission	5-speed with over drive
Number of axles		2	Electric system	24v
Operation control system		Electrically hydraulic control	Allowable passengers in cab	2+3
Equipment		max operation height≥15m,max operation radius≥7.3m,max working platform height ≥11.5m, working platform rating loading=200kg, working platform rating allowable passengers=2, working platform dimension: 6600x1900x2850,360°turning(left or right),4 H-shape legs. clients can choose hydraulic parts made in China or Italy,to be mentioned.
Engine		Beiqi Foton Motor Co., Ltd BJ1059VCAD6-2 95HP
Production cycle		25-30 days
