CLW Swing-arm Garbage Truck,garbage Disposal Truck,Garbage Truck

Chengli Special Automobile Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Drive Wheel:

4x2

Type:

Other, swing-arm garbage truck

Payment & Shipping

Payment Methods:

Port of Shipment:

ShangHai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Drive Wheel 4x2

Type Other, swing-arm garbage truck

Transmission Type Manual

Emission Standard Euro 2

Volume 6001 - 10000L

Fuel Type Diesel

Engine Capacity 5880

Size 6980*2490*3270

Gross Vehicle Weight 10815

Place of Origin Hubei, China

Brand Name CLW

Model Number CLW5108BZL

Certification ISO, BUREAU

Specifications

swing-arm garbage truck
can cooperate with several dustbins to improve the ability of cycle operation cycling time<60S

swing-arm garbage truck

Item		unit	parameter
Vehicle model			CLW5108BZL Container Garbage Truck
Chassis model			EQ1108G6DJ16
Overall dimensions		mm	698024903270
	Factual cubage	L	8000-10000
	GVW	kg	10815
	Rated loading capacity		4000
	Mass in working order		6870
	Body internal dimensions	mm	/
	Wheel base		3950
	F/R track base		1900/1800
	Approach/departure angle	°	30/18
Exhaust/hp		ml/kw	5880/118
Max speed		km/h	90
Tire specification		9.00-20,9.00R20	Engine type	EQB160-20
Traction system		4×2	transmission	6-speed with over drive
Number of axles		2	Electric system	24v
Operation control system		Electrically hydraulic control	Allowable passengers in cab	3
Equipment		Equipped with dustbin, hydraulic system and operating system Equipped with two advanced double acting hydrocylinders One vehicle can cooperate with several dustbins to improve the ability of cycle operation cycling time<60s
Engine		DongFeng Cummins Environmental Protection,supercharge,diesel engine(Europe 2)
Production cycle		20-25days
Company:		HuBei ChengLi Special Automobile Co.,Ltd
Country/Region:		China
