Home > Products > New Products > electric eleven seats shuttle bus, CE approved
electric eleven seats shuttle bus, CE approved
- 1000 Unit / Units per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- Toyota Coaster bus seat
- Toyota Coaster bus seat,kinglong bus seat, golden dragon bus seat,coaster bus seat
- Philippines Centro ISUZU MITSUBISHI TATA FUSO HINA SUZUKI FOTON Modern PUV electric folding bus door opener (BDM100-N)
- Philippines E-jeepney/electrical jeepney electric folding bus door opener (BDM100-N)
- Philippines PUV vehicles electric folding bus door opener (BDM100-N)
- Automobile electrical folding bus door pump
Product Details
Seats: | 11 - 20 | Emission Standard: | Other, electric | Transmission Type: | Automatic |
Max Speed: | 51 - 70 km/h | Steering Position: | LHD | Fuel Type: | Electric |
Dimensions (L x W x H) (mm): | 5000x1490x2050 | Place of Origin: | Jiangsu, China | Brand Name: | Eagle |
Model Number: | EG6118KB |
Product Description
electric fourteen shuttle bus
CE approved
with many options offered
Container loading qty | Disassembled | Assembled |
Qty/20' | 2units | 1unit |
Qty/40' | 4units | 2units |
Qty/40'HQ | 4units | 2units |
All electric vehicles sold by us are quality guaranteed.
We provide 13 months warranty to our electric vehicles from the shipping date.
Specifications | Model | EG6118KB |
Key Components | Power Source | Pure Electric |
Electric System | Both AC and DC system are available | |
Battery | Trojan battery | |
Motor | Chinese Motor | |
Controller | Curtis controller | |
Charger | China origin, input 110V-240V~50Hz-60Hz, | |
Performance | Passenger capacity | 11 |
Range (loaded) based on flat road at a speed of 20km/h (km)* | Up to 110 | |
Max. speed | Up to 50 | |
Minimum turning radius (m) | 5.35 | |
Max. climbing ability (loaded) | Up to 25% | |
Max. movement after brake at speed of 20km/h | ≤4m | |
Max. loading weight | 880kgs | |
Dimensions | Overall dimensions (mm) | 5000x1490x2050 |
Min. ground clearance (mm) | 135 | |
Wheelbase (mm) | 2710 | |
Front wheel tread (mm) | 1222 | |
Rear wheel tread (mm) | 1185 | |
Body and Frame | Frame | Welded steel framework with sand blasting+paint treatment |
Body | Fibreglass(the first seat bottom and dashboard), PP(other seat bottoms and front body) | |
Roof | Fibreglass+aluminum frame, with roof handle | |
Electric system | Lighting system and horn | Headlights,front turn signals, fog lights, rear turn signals, taillights,fog light, 1 reverse light, with DC-DC converter, horn. |
Steering and Suspension | Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function |
Brake system | Four wheel hydraulic drum brake+hand parking brake | |
Suspension system | Front suspension:Independent suspension, helix spring + shock absorber;Rear suspension:rear plate spring + shock absorber | |
Driving mode | Clutch, 4F+1R gear box, transmission shaft/Automatic Drive Sytem (Stepless Speed change system) | |
Rear axle | Integrated | |
Wheel & Tyre | 4J*12 Steel wheel, wheel cap, 155R12,8PR | |
Options | 2point seat belt | |
Overshadowing Curtain/Enclosure | ||
New seat | ||
Formed seat&backrest vinyl | ||
Inner rear view mirror | ||
License plate light | ||
CD player to replace MP3 receiver | ||
Microphone Wired | ||
with water sprayer | ||
Solar panel | ||
On-board charger | ||
Right hand drive system | ||
Electrical power steering | ||
Front disc brake and rear drum brake, with vacuum booster | ||
4J*12 Aluminum wheel, | ||
Body Color | Up to 6 kinds of standard color for option | |
Loading | Both Assembly and Disassembly are available |
Suzhou Eagle Electric Vehicle Manufacturing Co., Ltd. was founded 1999, and it's a leading manufacturer specialized in designing and manufacturing 4-wheel electric vehicles, includes: electric golf cart, electric utility car, electric personal carrier, electric shuttle bus, electric industrial car, various customized electric vehicles based on standard ones, etc.. It has a workshop area of 20,000 square meters with 2 assembly lines inside. Its daily production capacity is 80 units per day; this can be adjusted with the order volume increasing. It has around 300 workers including 50 engineers in R&D department and 15 engineers in QC department.
Suzhou Eagle takes quality as its lifeline. Eagle invests a lot to make production moulds, jigs and checking moulds to ensure precise component parts. Eagle invests a lot on checking machines like Salt spray test equipment for anti-rust ability, Rockwell hardness tester, Three-coordinate shock test-bed, Life test equipment, etc. to ensure component parts are produced and treated correctly. Eagle chooses the most top quality key component parts (Battery, Controller) to ensure the performance of its vehicles. In all, Eagle follows International Quality Standard to produce, control and inspect its electric vehicles. Hence, Eagle was awarded ISO9001-2000 Certificate in 2003 and Certificate of WMI Code (L4F) in 2006.
Eagle people believe good service has the same importance as good quality. Eagle’s sales persons can be reached in 24 hours x 365 days. Eagle’s sales persons are willing to answer any emails from their customers within 24 hours. Eagle provides all the spare parts (Except battery) of its vehicles.
With effective management and specialized talents, Suzhou Eagle is dedicated to offering top quality products with competitive price and first class after-sales service.
All electric golf carts sold by us are quality guaranteed.
We provide 13 months warranty to our electric vehicles from the shipping date.
