Help CenterBuggies Street Legal, 2 Passengers With Rear Cargo Box, EG6043KR-01,brand New
Related Products
-
Street Legal Golf Trolley With Seats and Long Cargo Box, EG2048HCXRNegotiableMOQ: 1 Unit -
Street Legal Electric Car With Cargo Box, EG2048HRNegotiableMOQ: 1 Unit
-
Road Legal Electric Buggy , EG2028HRNegotiableMOQ: 1 Unit
-
Road Legal Electric Vehicles, Lifted Suspension, Offroad Tire, EG2040ASZRNegotiableMOQ: 1 Unit
-
Street Legal Atv for Sale, Electric, Lifted Suspension, EG2020ASZR, Brand NewNegotiableMOQ: 1 Unit
| Item | Description |
| Controller | Curtis controller, 400A, imported from USA directly |
| Motor | Rated power 4KW (5.4HP), Chinese brand |
| Battery | Trojan battery, T105+, imported from USA directly |
| Charger |
High frequency onboard charger (input 90V-265V, 47-63HZ, output 48V/22A) |
| Item | Description |
| Passenger Capacity | 2 |
Range (loaded) (km)* |
up to 80 |
| Max.speed (km/h) | up to 40 |
| Min.turning radius (m) | 4 |
| Max.climbing ability(loaded) | up to 20% |
| Max. movement after brake at speed of 20km/h | ≤4m |
| Max.loading weight (kgs) | 320 |
| Charging time (hour) | 8-10 |
| Battery lifespan (cycles) | 750 |
* 1) based on the test conditions: 20km/h speed, flat and straight concrete road, wind speed less than 5m/s, temperature of 25 Celsius degree;
2) Range will vary depending on temperature, grade, payload and driving style.
| Item | Description |
| Overall dimensions (mm) | 3060x1400x1900 (LxWxH) |
| Rear cargo dimensions (mm) | 810x1040x250 (LxWxH) |
| Min.ground clearance (mm) | 155 |
| Wheelbase (mm) | 2080 |
| Front wheel tread (mm) | 1210 |
| Rear wheel tread (mm) | 1160 |
| Item | Description |
| Frame & Chassis | Welded steel framework with sand blasting and painting |
| Body | FRP and Plastic |
| Roof | FRP with steel frame, with roof handle |
| Windshield | Laminated glass (with E-mark) with wiper and water sprayer |
| Roof supports | Plastic |
| Seat | Reborn sponge with artificial leather, high back, with adjustable armrest |
| Rear cargo box | STS frame and aluminum board |
| Seatbelt | 3-point type, with E-mark |
| Floor | Bamboo floor with Skidproof leather |
| Dashboard | FRP, with F/R switch, emergency light switch, digital meter, combination switch, storage box (2), etc.. |
| Side rear view mirror | 2pcs, with E-mark |
| Item | Description |
| Lights | 12V, headlight (high/low beam), front turning light, rear brake light and rear turing light, all with E-mark |
| Horn | Electric horn, 12V |
| Reverse buzzer | Electric, 12V |
| Combination switch | including switch for headlight, turning light, wiper and horn |
| DC/DC converter | 48V/12V |
| Digital Meter | with Current meter, voltometer, speedometer, odometer and various indicators |
| Audio system | Radio with MP3 receiver and 2 waterproof speaker |
| Item | Description |
| Steering System |
Single-stage rack and pinion steering system, with automatic compensation function |
| Brake System | 4-wheel hydraulic drum brake with hand park brake |
| Accelerator | Resistance type, stepless speed change |
| Front suspension | Independent suspension |
| Rear suspension | integrated rear end, steel plate spring suspension, cylinder hydraulic vibration absorber |
| Driving mode | Rear axle two stage deceleration, motor direct driving |
| Rear axle | Integrated, Aluminum differential cage |
| Wheel & Tyre | 225/55b12 6PR tire, 12X7 aluminum wheel |
To increase the sales value of our vehicles, we also provide many optional accessories.
| Item | Option description | Item | Option description |
| 1 | Inner rear view mirror | 5 | CD player |
| 2 | Battery watering pipe | 6 | Wired mircophone |
| 3 | Water pump (handle) | 7 | Solar panel (built in) |
| 4 | Rain cover | |
| Container loading qty | Semi-knock-down | Refer Picture |
| 20'ft GP | 2 | |
| 40'ft GP | 6 | |
| 40'HQ | 6 |
- Customization is available
- 13 months warranty from shipping date
- FOC spare parts provided
Suzhou Eagle Electric Vehicle Manufacturing Co., Ltd. was founded 1999, and it's a leading manufacturer specialized in designing and manufacturing 4-wheel electric vehicles, includes: electric golf cart, electric utility car, electric personal carrier, electric shuttle bus, electric industrial car, various customized electric vehicles based on standard ones, etc..
Eagle follows International Quality Standard to produce, control and inspect its electric vehicles. Hence, Eagle was awarded ISO9001-2000 Certificate in 2003 and Certificate of WMI Code (L4F) in 2006.
