Home > Products > Special Electric Vehicle > CE approved Special Electric ambulance golf car for cruiser, EG2028TB1

CE approved Special Electric ambulance golf car for cruiser, EG2028TB1

FOB Price

Negotiable / Unit

1 Unit(Min.Order)

Supply Ability 2000 Unit / Units per Month
Port shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Seats	1 - 2		Fuel Type	Electric
Battery Voltage	48V		Certification	CE

Product Description

CE approved Special Electric ambulance golf car for cruiser,

_{----EG2028TB1}

Model	EG2028TB1
Battery	8xT105(185Ah@5hr rate)
Motor	3.8KW Chinese motor
Controller	Curtis 1268 (400A@2minutes)

Dimensions
Overall dimensions (mm)	2670X1180X1800
Min. ground clearance (mm)	120
Wheelbase (mm)	1700
Front wheel tread (mm)	855
Rear wheel tread (mm)	975

Electric system
Lighting system and horn	2 headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with DC-DC converter (converting from 48V to 12V), horn.
Charger	China origin, input 110V-240V~50Hz-60Hz, output 36V/48V, 25A

Steering and Suspension
Steering system	Single-stage rack and pinion steering system, automatic rocker compensating function
Brake system	Mechanical brake
Accelerator	Stepless speed change
Suspension system	Front and rear plate spring + cylinder hydraulic shock absorber
Driving mode	Rear axle two stage deceleration, motor direct driving
Rear axle	Integrated, Gear ratio 12.76:1
Wheel & Tyre	10x6 Alumimum wheel & 205/50-10 4PR

Body and Frame
Frame	Welded steel framework with phosphate+electro-coating treatment
Body	PP plastic front body + PP plastic rear body
Roof	Injected plastic
Windshield	one-piece Organic glass

Performance
Passenger capacity	4
Range (loaded) based on flat road at a speed of 20km/h (km)＊	>80
Max. speed @12.76:1 gear ratio	32
Minimum turning radius (m)	3.5
Max. climbing ability (loaded) @ 12.76:1 gear ratio	20%
Max. climbing ability (loaded) @ 10.26:1 gear ratio	15%
Max. movement after brake at speed of 20km/h	≤4m
Max. loading weight	320kgs
Net weight	N/A

Specifications

* 1) based on the test conditions: 20km/h speed, flat and straight concrete road, wind speed less than 5m/s, temperature of 25 Celsius degree;

2) Range will vary depending on temperature, grade, payload and driving style.

Detailed Images

Packing & Delivery

Our most professional packaging

Transport of large trucks to the seaport

And international transport cooperation

Container loading qty	Disassembled
20'ft GP	6units
40'ft GP	14units
40'HQ	21units
