Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Seats:
1 - 2
Fuel Type:
Electric
Battery Voltage:
48V
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CE Approved Special Electric Ambulance Golf Car for Cruiser, EG2028TB1NegotiableMOQ: 1 Unit -
CE Approved Special Electric Ambulance Golf Car for Cruiser, EG2028TB1 Electric Car Without Driving LicenceNegotiableMOQ: 1 Unit
-
CE Approved Special Electric Ambulance Golf Car for Cruiser, EG2028TBNegotiableMOQ: 1 Unit
-
Special Electric Ambulance Golf Car for Cruiser, EG2028TB1NegotiableMOQ: 1 Unit
-
Electric Ambulance Car for Cruiser, EG2048TB1NegotiableMOQ: 1 Unit
Seats
1 - 2
Fuel Type
Electric
Battery Voltage
48V
Certification
CE
Application
The electric airport people movers EG2048T can be used in the airport, factory, railway station and any closed area where need to carry luggage quietly.
Key Components
| Item | Description |
| Controller | Curtis controller, 275A-400A, imported from USA directly |
| Motor | Rated 3KW-5KW (4.08HP-6.8HP), ADC brand or Chinese brand Both DC motor and AC motor are available |
| Battery | Trojan battery, T875 or T105+, imported from USA directly |
| Charger | High Frequency onboard charger (input 90V-265V, 47-63HZ, output 48V/22A, 36V,25A) |
Performance
| Item | Description |
| Passenger Capacity | 4 |
Range (loaded) (km)* | up to 100 |
| Max.speed (km/h) | up to 40 |
| Min.turning radius (m) | 4.5 |
| Max.climbing ability(loaded) | up to 25% |
| Max. movement after brake at speed of 20km/h | ≤4m |
| Max.loading weight (kgs) | 370 |
| Charging time (hour) | 8-10 |
| Battery lifespan (cycles) | 750 |
* 1) based on the test conditions: 20km/h speed, flat and straight concrete road, wind speed less than 5m/s, temperature of 25 Celsius degree;
2) Range will vary depending on temperature, grade, payload and driving style.
Dimensions
| Item | Description |
| Overall dimensions (mm) | 3110x1180x1500 (LxWxH) |
| Min.ground clearance (mm) | 120 |
| Wheelbase (mm) | 2450 |
| Front wheel tread (mm) | 855 |
| Rear wheel tread (mm) | 975 |
Body and Frame
| Item | Description |
| Frame & Chassis | Welded steel framework with phosphate+electro-coating treatment |
| Body | PP plastic front and rear body cover, injected |
| Roof | FRP |
| Windshield | One-piece organic glass (PMMA) |
| Roof supports | Carbon steel, powder coated, black |
| Cushion | Reborn sponge with artificial leather and plastic bottom cover |
| Backrest | Reborn sponge with artificial leather and plastic cover |
| Armrest | Formed |
| Floor mat | Skidproof rubber |
| Centre sweater basket | Carbon steel, large volume |
| Golf bag holder | Steel support with nylon strap |
| Dashboard | Black plastic, with F/R switch, battery power indicator, ignition key on it |
| Beverage holders | 4 cups holders, 2 big and 2 small |
| Side trim | Extruded aluminum |
| Score card holder | On the steering wheel |
Electric System
| Item | Description |
| Lights | 12V, headlight, front turning light, taillight (brake light and rear turing light) |
| Horn | Electric horn, 12V |
| Reverse buzzer | Electric, 12V |
| Combination switch | |
| DC/DC converter | 36V/12V, 48V/12V |
Steering & suspersion
| Item | Description |
| Steering System | Single-stage rack and pinion steering system, with automatic compensation function |
| Brake System | Rear wheel mechanical brake with foot park brake |
| Accelerator | Resistance type, stepless speed change |
| Front suspension | Cylinder hydraulic shock absorber and leaf spring |
| Rear suspension | Cylinder hydraulic shock absorber and leaf spring |
| Driving model | Rear axle two stage deceleration, motor direct driving |
| Rear axle | Aluminum differential cage, integrated, 12.76:1 gear ratio |
| Wheel & Tyre | 10x6 Alumimum wheel & 205/50-10 4PR |
Option Accessories
To increase the sales value of our electric airport people movers, we also provide many optional accessories.
| Item | Option description | Item | Option description |
| 1 | Hinged windshield | 11 | Enclosure |
| 2 | Laminated windshield with wiper | 12 | Digital meter |
| 3 | 2-point seatbelt | 13 | 12V plug |
| 4 | Backrest cover in wood finish | 14 | Hour meter |
| 5 | Steering wheel in wood finish | 15 | Solar panel |
| 6 | Inner rear view mirror | 16 | Cooler box |
| 7 | Side rear view mirror | 17 | Battery watering pipe |
| 8 | STS or aluminum roof supports | 18 | Water pump (handle) |
| 9 | Wooden finish dashboard,steering wheel and dashboard | 19 | 4-wheel hydraulic front drum or disc, rear drum brake with hand park brake |
| 10 | Glove box with door and lock | 20 | 8x7 steel rim with 18x8.5-8 tyre or 6J-10 steel rim with 205/50-10 tyre |
We provide several color options for our electric airport people movers as below. And customized color is also available with extra cost
| Item | Pure white | Pure black | Coca cola red |
Body (including roof) | |||
| Metallic green | Champagne | Navy blue | |
Packing & Shipping
Electric airport people movers will be packed in steel crate
| Container loading qty | Semi-knock-down | Refer Picture |
| 20'ft GP | 4 | |
| 40'ft GP | 12 | |
| 40'HQ | 18 |
Warranty
All electric airport people movers sold by us are quality guaranteed.
We provide 13 months warranty to our electric vehicles from the shipping date.
