Electric Mini Bus for Sale, 11 Seater, CE Approved

Suzhou Eagle Electric Vehicle Manufacturing Co., Ltd.
Electric Mini Bus for Sale, 11 Seater, CE Approved thumbnail-1
Electric Mini Bus for Sale, 11 Seater, CE Approved photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Power:
Electric
Place of Origin:
Jiangsu, China
Brand Name:
Eagle
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Power Electric
Place of Origin Jiangsu, China
Brand Name Eagle
Model Number EG6118KB

Electric mini bus for sale, 11 seater, CE approved

Product Description



ModelEG6118KA02EG6118KA04
System72V/5KW Series72V/7.5KW AC system
Key Components
Battery12xT105(185Ah@5hr rate)12xT105(185Ah@5hr rate)
Motor5KW Chinese motor7.5KW Chinese motor
ControllerCurtis 1205M (400A@1minute)Zapi AC2(400A@2minute)
Performance
Passenger capacity1111
Range (loaded) based on flat road at a speed of 20km/h (km)*>100>110
Max. speed (km/h)3240
Minimum turning radius (m)4.54.5
Max. climbing ability (loaded) 15%20%
Max. movement after brake at speed of 20km/h≤4m≤4m
Max. loading weight880kgs880kgs
Net weight1080kgs1129kgs
Dimensions
Overall dimensions (mm)4230X1490X2050
Min. ground clearance (mm)140
Wheelbase (mm)1900
Front wheel tread (mm)1210
Rear wheel tread (mm)1200
Detailed Configurations: ("S" stands for Standard configuration and "O" stands for Optional configuration)
Body and Frame
FrameWelded steel framework with sand blasting+paint treatment
BodyFibreglass
Standing board handrailSteel with paint
Stainless Steel
RoofFibreglass+aluminum frame, with roof handle
WindshieldLaminated glass
2point seat belt8pcs
2point seat belt11pcs
Overshadowing Curtain
EnclosurePVC
Large Seats:
     1) backrest and cushionSponge + artificial leather
     2) armrestAluminum
New seatBackrest and seat cushion be separated
FloorBamboo + artificial leather
Cup drinker holder1pc
Inner rear view mirrorOne piece per cart in the middle of the windshield
Side rear view mirrorTwo pieces per cart
Battery watering system,48V systemwithout water supply tool
Battery watering system,72V systemwithout water supply tool
Manual Pumpwater supply tool (other water supply tools are available)
Emergency power-off button/
Police lights with the loud speaker/
Electric system
Lighting system and hornFront: 2 Headlights (High beam and dipped headlight), 2 front turn signals, 2 fog lights; Back: 2 rear turn signals, 2 taillights(position light & brake light), 1 fog light, 1 reverse light),with DC-DC converter (converting from 48V to 12V) , horn.
License plate light12V
DashboardVoltameter, ammeter, speedometer, turn signal indicator, headlight indicator, emergency switch, fog light switch; Headlight switch, turn signal switch, wiper switch, horn button;
Audio SystemRadio and MP3 receiver
CD player to replace MP3 receiver
MicrophoneWired
Speaker4pcs
Reversing alarm
Switch assemblyLights switch, horn switch, wiper switch
Wiper12V
with water sprayer
Solar panel72V/270W
ChargerChina origin, input 110V-240V~50Hz-60Hz, output 48V, 25A
Steering and Suspension
Steering systemSingle-stage rack and pinion steering system, automatic rocker compensating function
Right hand drive system
Electrical power steering
Brake systemFour wheel hydraulic drum brake+hand parking brake
Front disc brake and rear drum brake, with vacuum booster
Drive systemAutomatic drive system (stepless speed change)
Front suspensionIndependent suspension, helix spring + shock absorber
Rear suspensionrear plate spring + shock absorber
Wheel & Tyre4J*12 Steel wheel, wheel cap, 155R12C,8PR
4J*12 Aluminum wheel,



Color

 Electric mini bus for sale, 11 seater, CE approved



Packaging & Shipping

 Electric mini bus for sale, 11 seater, CE approved



Company Information

 Electric mini bus for sale, 11 seater, CE approved



Certifications

 Electric mini bus for sale, 11 seater, CE approved



Our Services



All electric golf carts sold by us are quality guaranteed.

We provide 13 months warranty to our electric vehicles from the shipping date.
