Home > Transportation > Specialized Vehicle > Garbage Truck > Electric Mini Garbage Collecting Car, CE Approved
Electric Mini Garbage Collecting Car, CE Approved
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Drive Wheel:
4x2
Type:
Other, Collection
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Electric Garbage Truck With Tail Gate Tipper, 1000kgs Loading Weight, Simple Enclosed Cab, EG6023XA1NegotiableMOQ: 1 Unit -
Electric Industrial Vehicle, Scissor Lifter, 6m Lifting Height ,EG6060JNegotiableMOQ: 1 Unit
-
Electric Cargo Van, EG6042H ,CE Approved ,2 SeatsNegotiableMOQ: 1 Unit
-
Electric Burden Carrier, EG6032H ,CE Approved ,2 SeatsNegotiableMOQ: 1 Unit
-
Industrial Electric Carts EG6030HNegotiableMOQ: 1 Unit
Condition
New
Drive Wheel
4x2
Type
Other, Collection
Transmission Type
Automatic
Volume
1000 - 3000L
Place of Origin
Jiangsu, China
Brand Name
Eagle
Model Number
EG6020X
Certification
CE
Electric mini garbage collecting car, CE approved
Product Description
| Model | EG6020X | EG6020X01 |
| System | 48V/4KW Series | 48V/5KW AC Series |
| Key Components | ||
| Battery | 8xT105(185Ah@5hr rate) | 8xT105(185Ah@5hr rate) |
| Motor | 3.8KW Chinese motor | 5KW AC motor |
| Controller | Curtis 1204 (275A@2minutes) | Zapi ACE2 (400A@2minutes) |
| Performance | ||
| Passenger capacity | 2 | 2 |
| Range (loaded) based on flat road at a speed of 20km/h (km)* | >70 | >80 |
| Max. speed @12.49:1 gear ratio | 30 | 40 |
| Max. speed @10.25:1 gear ratio | / | / |
| Minimum turning radius (m) | 4 | 4 |
| Max. climbing ability (loaded) @ 12.49:1 gear ratio | 15% | 15% |
| Max. movement after brake at speed of 20km/h | ≤4m | ≤4m |
| Max. loading weight | 500kgs | 500kgs |
| Net weight | 1060kgs | 1068kgs |
| Dimensions | ||
| Overall dimensions (mm) | 3750X1400X1810 | |
| Rear garbage bin | 1720X1090X1170 | |
| Min. ground clearance (mm) | 140 | |
| Wheelbase (mm) | 2450 | |
| Front wheel tread (mm) | 1160 | |
| Rear wheel tread (mm) | 1150 | |
| Detailed Configurations: ("S" stands for Standard configuration and "O" stands for Optional configuration) | ||
| Body and Frame | ||
| Frame | Welded steel framework with sand blasting+paint treatment | |
| Body | Fibreglass | |
| Roof | Fibreglass+steel frame | |
| Windshield | Laminated glass | |
| 3point seat belt | 2pcs | |
| Large Seats: | ||
| 1) backrest and cushion | Sponge + artificial leather | |
| 2) armrest | Soft expanded plastic | |
| Floor | Bamboo + artificial leather | |
| Inner rear view mirror | One piece per cart in the middle of the windshield | |
| Side rear view mirror | Two pieces per cart | |
| Battery watering system,48V system | without water supply tool | |
| Manual Pump | water supply tool (other water supply tools are available) | |
| Rain cover | PVC | |
| Electric system | ||
| Lighting system and horn | 2 headlights, 2 front turn signals, 2 rear turn signals and 2 rear brake lights, with DC-DC converter (converting from 48V to 12V), horn. | |
| Dashboard | forward/reverse switch, headlight indicator, turn signal indicator, ignition key, voltameter, ammeter, emergency switch; turn signal switch, headlight switch, windscreen wiper switch, horn button; Storage for miscellaneous items | |
| Audio System | Radio and MP3 receiver | |
| CD player to replace radio | ||
| Microphone | Wired | |
| Speaker | 2pcs | |
| Reversing alarm | ||
| Switch assembly | Lights switch, horn switch, wiper switch | |
| Wiper | 12V | |
| Motor for lifting system | 24V,0.8KW | |
| Charger | China origin, input 110V-240V~50Hz-60Hz, output 48V, 25A | |
| Steering and Suspension | ||
| Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function | |
| Brake system | Four wheel hydraulic drum brake+foot parking brake | |
| Accelerator | Stepless speed change | |
| Front suspension | Independent suspension, helix spring + shock absorber | |
| Rear suspension | rear plate spring + shock absorber | |
| Driving mode | Rear axle two stage deceleration, motor direct driving | |
| Rear axle | Integrated, Gear ratio12.49:1 | |
| Wheel & Tyre | 20.5x8.0-10 tire, 6J-10 steel wheel, wheel cap | |
| 10X6 Aluminum Wheel | ||
Color
Packaging & Shipping
| Container loading qty | Assembled |
| Qty/20' | 1 |
| Qty/40' | 2 |
| Qty/40'HQ | 2 |
Company Information
Certifications
After-Sales Service
All electric golf carts sold by us are quality guaranteed.
We provide 13 months warranty to our electric vehicles from the shipping date.
