Home > Transportation > Specialized Vehicle > Fire Truck > Small Size Electric Fire Fighting Vehicle , CE Approved
Small Size Electric Fire Fighting Vehicle , CE Approved
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Drive Wheel:
4x2
Transmission Type:
Automatic
Condition:
New
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Electric Garbage Barrel Collection Truck, CE ApprovedNegotiableMOQ: 1 Unit -
Electric Refuse Truck With Side Loading for Recovery, CE ApprovedNegotiableMOQ: 1 Unit
-
Electric High Pressure Water Cleaning Truck With CE CertificateNegotiableMOQ: 1 Unit
-
Electric Collection Truck for Liquid Waste , CE ApprovedNegotiableMOQ: 1 Unit
-
Electric Mini Garbage Collecting Car, CE ApprovedNegotiableMOQ: 1 Unit
Drive Wheel
4x2
Transmission Type
Automatic
Condition
New
Place of Origin
Jiangsu, China
Brand Name
Eagle
Model Number
EG6010F
small size Electric fire fighting vehicle , CE approved
Product Description
| Model | EG6010F | EG6010F04 | |
| Description | Electric fire truck | Electric fire truck | |
| System | 48V/4KW Series | 48V/5KW AC | |
| Key Components | |||
| Battery | 8xT105(185Ah@5hr rate) | 8xT105(185Ah@5hr rate) | |
| Motor | 3.8KW Chinese motor | 5KW Chinese motor | |
| Controller | Curtis 1204(275A@2minutes) | Zapi ACE2 (400A@2minutes) | |
| Performance | |||
| Passenger capacity | 4 | 4 | |
| Range (loaded) based on flat road at a speed of 20km/h (km) | >60 | >70 | |
| Max. speed(km/h) | 32 | 32 | |
| Minimum turning radius (m) | 3.8 | 3.8 | |
| Max. climbing ability (loaded) | 18% | 18% | |
| Max. movement after brake | ≤4m | ≤4m | |
| Max. loading weight | |||
| Net weight | |||
| Dimensions | |||
| Overall dimensions (mm) | |||
| Rear garbage bin | |||
| Min. ground clearance (mm) | 140 | ||
| Wheelbase (mm) | 2450 | ||
| Front wheel tread (mm) | 1160 | ||
| Rear wheel tread (mm) | 1150 | ||
| Detailed Configurations: ("S" stands for Standard configuration and "O" stands for Optional configuration) | |||
| Body and Frame | |||
| Frame | Welded steel framework with sand blasting+paint treatment | ||
| Body | Fibreglass | ||
| Roof | Fibreglass+steel frame | ||
| Rear box | Aluminum box + rolling door | ||
| Windshield | Laminated glass | ||
| Seats | Black | ||
| Floor | Anti-sliding ruber floor mat | ||
| Side rear view mirror | Two pieces per cart | ||
| Inner rear view mirror | One piece per cart in the middle of the windshield | ||
| Seatbelt | 3-point, 2pcs | ||
| Enclosure | PVC | ||
| Overshadowing Curtain | |||
| Powder fire extinguisher | 3kgs | ||
| Fire Axe | |||
| Semicircular fire barrel | |||
| Fire pliers | |||
| Escape hammer | |||
| Fire spade | |||
| Crowbar | |||
| Life line | |||
| Stream fire water gun | |||
| Spray fire water gun | |||
| Electric system | |||
| Lighting system and horn | Headlight, turning light, taillight (brake light and position light) with DC-DC converter (converting from 48V to 12V), horn. | ||
| Dashboard | digital meter with indicator, emergency switch; combined switch, F/R switch | ||
| Audio System | Radio and MP3 adaptor | ||
| CD Player | To replace Radio | ||
| Microphone | wired | ||
| Speaker | 2pcs | ||
| Reversing alarm | |||
| Switch assembly | Lights switch, horn switch, wiper switch | ||
| Wiper | 12V, 50W, single arm | ||
| Fire Siren | |||
| Rotating beacon | 2pc | ||
| Emergency power-off button | |||
| Charger | China origin, input 110V-240V~50Hz-60Hz, output 48V, 25A | ||
| Steering and Suspension | |||
| Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function | ||
| Brake system | Four wheel hydraulic drum brake+ foot parking brake | ||
| Accelerator | Stepless speed change | ||
| Front suspension | Independent suspension, helix spring + shock absorber | ||
| Rear suspension | rear plate spring + shock absorber | ||
| Rear axle | Integrated, Gear ratio 12.76:1 | ||
| Integrated, Gear ratio 10.26:1 | |||
| Drive mode | Rear axle two stage deceleration, motor direct driving | ||
| Wheel & Tyre | 20.5x8.0-10 tire, 6J-10 steel wheel, wheel cap | ||
| 10X6 Aluminum rim | |||
