Help Centeroff Road 6 Seater Electric Sports Utility Vehicle
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer, Trading Company
Year Established:
1999
Factory Size:
10,000-30,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Electric Hunting Vehicle,2 Seats With Cargo Bed, off Road, CE ApprovedNegotiableMOQ: 1 Unit -
off Road Electric ATV,4 Seats With Cargo Bed , CE ApprovedNegotiableMOQ: 1 Unit
-
Electric Huntting Buggy, 2 Seats With Cargo Box, CE Approved,best Lightweight Golf Buggy EG2020TNegotiableMOQ: 1 Unit
-
Electric Hunting Buggy, off Road, CE ApprovedNegotiableMOQ: 1 Unit
-
Electric Hunting Buggy, 4 Wheel Drive, CE ApprovedNegotiableMOQ: 1 Unit
off road 6 seater Electric sports utility vehicle
Product Description
| Model | EG2040ASZ | EG2040ASZ02 | EG2040ASZ04 |
| System | 48V/4KW Sepex | 48V/5.3KW Sepex | 48V/5KW AC System |
| Key Components | |||
| Battery | 8xT105(185Ah@5hr rate) | 8xT105(185Ah@5hr rate) | 8xT105(185Ah@5hr rate) |
| Motor | 3.8KW Chinese motor | 5.3KW Chinese Motor | 5KW Chinese Motor |
| Controller | Curtis 1268 (400A@2minutes) | Curtis 1268 (400A@2minutes | Zapi ACE2(400A@2minutes) |
| Performance | |||
| Passenger capacity | 6 | 6 | 6 |
| Range (loaded) based on flat road at a speed of 20km/h (km)* | >55 | >55 | >60 |
| Max. speed @12.49:1 gear ratio | 32 | 32 | 40 |
| Minimum turning radius (m) | 4.5 | 4.5 | 4.5 |
| Max. climbing ability (loaded) @ 12.49:1 gear ratio | 20% | 20% | 20% |
| Max. movement after brake at speed of 20km/h | ≤4m | ≤4m | ≤4m |
| Max. loading weight | 480kgs | 480kgs | 480kgs |
| Net weight | 720kgs | 720kgs | 746kgs |
| Dimensions | |||
| Overall dimensions (mm) | 3500x1340x2100 | ||
| Min. ground clearance (mm) | |||
| Wheelbase (mm) | 2440 | ||
| Front wheel tread (mm) | 850 | ||
| Rear wheel tread (mm) | 975 | ||
| Detailed Configurations: ("S" stands for Standard configuration and "O" stands for Optional configuration) | |||
| Body and Frame | |||
| Frame | Welded steel framework with phosphate+electro-coating treatment | ||
| Body | PP plastic front body + PP plastic rear body | ||
| Color (front body, rear body, middle seat pot) | camouflaged | ||
| solid color | |||
| Roof | Fibreglass | ||
| Windshield | one-piece Organic glass | ||
| Windshield, hinged | |||
| Laminated windshield | |||
| Laminated windshield with wiper | |||
| 2point seat belt | |||
| front bumper | Carbon steel, powder coating | ||
| front basket | Carbon steel, powder coating | ||
| Large Seats: | |||
| 1) backrest and cushion | Rebond seat + artificial leather | ||
| 2) armrest | Formed | ||
| 3) plastic seat bottom | |||
| Formed seat&backrest vinyl | not include rear flip-flop seat | ||
| Backrest cover in wood finish | |||
| Floor | rubber | ||
| Dashboard in black plastic | forward/reverse switch, battery capacity indicator, ignition key | ||
| Dashboard in wood finish | |||
| Steering wheel in wood finish | |||
| Beverage holders | 4 cups drink holders | ||
| Glove box | |||
| Glove box door (include two locks) in black plastic | 2 doors per set | ||
| Glove box door (include two locks) in wood finish (inside and outside) | 2 doors per set | ||
| Side trim | aluminium | ||
| Score card holder | on steering wheel | ||
| Towing bracket | on front of golf car | ||
| Inner rear view mirror | One piece per cart in the middle of the windshield | ||
| Side rear view mirror | Two pieces per cart | ||
| Battery watering system,48V system | without water supply tool | ||
| Manual Pump | water supply tool (other water supply tools are available) | ||
| Enclosure | |||
| Electric system | |||
| Lighting system and horn | 2 headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with DC-DC converter (converting from 48V to 12V), horn. | ||
| Reversing alarm | |||
| Meter(only available for 48V system) | speed, mileage, headlight indicator, emergency light indicator, turn signal indicator, reverse indicator | ||
| 12V accessory plug | to be mounted on the dashboard | ||
| Hour meter | |||
| bagwell liner | |||
| Solar Panel | 48V, 185W | ||
| Charger | China origin, input 110V-240V~50Hz-60Hz, output 48V, 25A | ||
| Steering and Suspension | |||
| Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function | ||
| Brake system | Mechanical brake | ||
| 4-wheel hydraulic brake + hand brake | |||
| Accelerator | Stepless speed change | ||
| Suspension system | Front and rear plate spring + vibration absorber | ||
| Driving mode | Rear axle two stage deceleration, motor direct driving | ||
| Rear axle | Integrated, Gear ratio 12.49:1 | ||
| Wheel & Tyre | 22 x 11-10 tyre, 10*8 Steel wheel | ||
| 22 x 11-10 tyre, 10*8 Aluminum wheel | |||
| 24x8-12 tyre, 12*7 Steel wheel | |||
| 24x8-12 tyre, 12*7 Aluminum wheel | |||
Color
Packaging & Shipping
| Container loading qty | Disassembled(with top basket, front basket, front bumper | Disassembled (without top basket, front basket, front bumper) |
| Qty/20' | 4units | 4units |
| Qty/40' | 10units | 12units |
| Qty/40'HQ | 14units | 15units |
Company Information
Certifications
After-Sales Service
All electric golf carts sold by us are quality guaranteed.
We provide 13 months warranty to our electric vehicles from the shipping date.
