Home > Sporting Goods & Recreation > Camping & Outdoor Gear > Hunting Supplies > Electric Hunting Buggy, off Road, CE Approved

Electric Hunting Buggy, off Road, CE Approved

Name: Electric Hunting Buggy, off Road, CE Approved
Brand: Eagle
SKU: 140811702
Availability: InStock

Electric Hunting Buggy, off Road, CE Approved thumbnail-1

Electric Hunting Buggy, off Road, CE Approved photo-1

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Brand Name:

Eagle

Model Number:

EG2020ASZ

Contact Supplier Request Quote Chat Now

Suzhou Eagle Electric Vehicle Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Brand Name Eagle

Model Number EG2020ASZ

Type Other, Hunting buggy

Electric hunting buggy, off road, CE approved

Product Description

Model	EG2020ASZ	EG2020ASZ02	EG2020ASZ04
System	48V/4KW Sepex	48V/5.3KW Sepex	48V/5KW AC System
Key Components
Battery	8xT105(185Ah@5hr rate)	8xT105(185Ah@5hr rate)	8xT105(185Ah@5hr rate)
Motor	3.8KW Chinese motor	5.3KW Chinese Motor	5KW Chinese Motor
Controller	Curtis 1268 (400A@2minutes)	Curtis 1268 (400A@2minutes	Zapi ACE2(400A@2minutes)
Performance
Passenger capacity	4	4	4
Range (loaded) based on flat road at a speed of 20km/h (km)^*	>70	>70	>75
Max. speed @12.49:1 gear ratio	32	32	32
Minimum turning radius (m)	3	3	3
Max. climbing ability (loaded) @ 12.49:1 gear ratio	20%	22%	22%
Max. movement after brake at speed of 20km/h	≤4m	≤4m	≤4m
Max. loading weight	320kgs	320kgs	320kgs
Net weight	611kgs	611kgs	637kgs
Dimensions
Overall dimensions (mm)	2950x1340x1990
Min. ground clearance (mm)	N/A
Wheelbase (mm)	1680
Front wheel tread (mm)	850
Rear wheel tread (mm)	975
Detailed Configurations: ("S" stands for Standard configuration and "O" stands for Optional configuration)
Body and Frame
Frame	Welded steel framework with phosphate+electro-coating treatment
Body	PP plastic front body + PP plastic rear body
Color (front body, rear body and top)	camouflaged
	solid color
Roof	Fibreglass
Windshield	one-piece Organic glass
	Organic glass Windshield, hinged
	laminated windshield
	laminated windshield with wiper
2point seat belt
front bumper	Carbon steel, powder coating
front basket	Carbon steel, powder coating
top basket	Carbon steel, powder coating
Large Seats(front seat):
1) backrest and cushion	Rebond seat + artificial leather
2) armrest	Formed
3) plastic seat bottom
Formed seat&backrest vinyl	not include rear flip-flop seat
Backrest cover in wood finish
Floor	rubber
Dashboard in black plastic	forward/reverse switch, battery capacity indicator, ignition key
Dashboard in wood finish
Steering wheel in wood finish
Beverage holders	4 cups drink holders
Glove box
Glove box door (include two locks) in black plastic	2 doors per set
Glove box door (include two locks) in wood finish (inside and outside)	2 doors per set
Side trim	aluminium
Score card holder	on steering wheel
Towing bracket	on front of golf car
Inner rear view mirror	One piece per cart in the middle of the windshield
Side rear view mirror	Two pieces per cart
Battery watering system,48V system	without water supply tool
Manual Pump	water supply tool (other water supply tools are available)
Enclosure
Electric system
Lighting system and horn	2 headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with DC-DC converter (converting from 48V to 12V), horn.
Reversing alarm
Meter(only available for 48V system, not available for Curtis AC controller)	speed, mileage, headlight indicator, emergency light indicator, turn signal indicator, reverse indicator
12V accessory plug	to be mounted on the dashboard
Hour meter
bagwell liner
Solar Panel	48V, 185W
Charger	China origin, input 110V-240V~50Hz-60Hz, output 48V, 25A
Steering and Suspension
Steering system	Single-stage rack and pinion steering system, automatic rocker compensating function
Brake system	Mechanical brake
Brake system	4-wheel hydraulic brake + hand brake
Accelerator	Stepless speed change
Suspension system	Front and rear plate spring + vibration absorber
Driving mode	Rear axle two stage deceleration, motor direct driving
Rear axle	Integrated, Gear ratio 12.49:1
Wheel & Tyre	22 x 11-10 tyre, 10*8 Steel wheel
	22 x 11-10 tyre, 10*8 Aluminum wheel
	24x8-12 tyre, 12*7 Steel wheel
	24x8-12 tyre, 12*7 Aluminum wheel

Color

Packaging & Shipping

Container loading qty	Disassembled(with top basket, front basket, front bumper	Disassembled (without top basket, front basket, front bumper)
Qty/20'	6units	6units
Qty/40'	12units	14units
Qty/40'HQ	18units	20units
