Electric hunting buggy, 4 wheel drive, CE approved

FOB Price

Negotiable / Unit

1 Unit(Min. Order)

Port Shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	Eagle
Model Number	EG6020A4D		Type	Other, Hunting buggy

Product Description

Electric hunting buggy, 4 wheel drive, CE approved

Product Description

Model	EG6020A4D
System	48V/4KW Sepex
Key Components
Battery	8xT105(185Ah@5hr rate)
Motor	Front 3.8KW Chinese motor+rear 5.3KW Chinese motor
Controller	2XCurtis 1244 (400A@2minutes)
Performance
Passenger capacity	4
Range (loaded) based on flat road at a speed of 20km/h (km)^*	>40
Max. speed @12.49:1 gear ratio	32
Minimum turning radius (m)	3.8(150inch)
Max. climbing ability (loaded) @ 12.49:1 gear ratio	45%
Max. movement after brake at speed of 20km/h	≤4m
Max. loading weight	320kgs(882lbs)
Net weight	840kgs
Dimensions
Overall dimensions (mm)	3030x1395x1990(without searching light)
Min. ground clearance (mm)	415(16inch)
Wheelbase (mm)	1660
Front wheel tread (mm)	850
Rear wheel tread (mm)	975
Detailed Configurations: ("S" stands for Standard configuration and "O" stands for Optional configuration)
Body and Frame
Chassis	Welded steel framework with phosphate+electro-coating treatment
Roof frame	Steel frame with phosphate+powder coating treatment,black color
	Roof frame in camo color
Body	PP plastic front body + PP plastic rear body
Color (front body, rear body and top)	camouflaged
	solid color
Roof	Fibreglass
	Canvas
Windshield	one-piece Organic glass
	Windshield, hinged
	laminated windshield
	laminated windshield with wiper
3point seat belt
front bumper	Carbon steel, powder coating
	Front bumper in camo color
Metallic steel guard above front body	Carbon steel, powder coating
Front basket	Carbon steel, powder coating
Top basket	Carbon steel, powder coating
Gun holder
Towing bar
Large Seats:
1) backrest and cushion	Rebond seat + artificial leather
	backrest and cushion in camo
2) armrest	Formed
3) plastic seat bottom
Formed seat&backrest vinyl	not include rear flip-flop seat
Backrest cover in wood finish
Floor	rubber
Dashboard in black plastic	battery power meter, power key, F/R switch, 4WD and 2WD switching button, winch switch; switch for searchlight (option)
Dashboard in wood finish
Steering wheel in wood finish
Beverage holders	4 cups drink holders
Glove box
Glove box door (include two locks) in black plastic	2 doors per set
Glove box door (include two locks) in wood finish (inside and outside)	2 doors per set
Side trim	stainless steel
Wheel fender in camo
Score card holder	on steering wheel
Inner rear view mirror	One piece per cart in the middle of the windshield
Side rear view mirror	Two pieces per cart
Battery watering system,48V system	without water supply tool
Manual Pump	water supply tool (other water supply tools are available)
Electric system
Lighting system and horn	2 headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with DC-DC converter (converting from 48V to 12V), horn.
Reversing alarm
Meter(only available for 48V system)	speed, mileage, headlight indicator, emergency light indicator, turn signal indicator, reverse indicator
12V accessory plug	to be mounted on the dashboard
Winch
Searching light	4pcs
Hour meter
Charger	China origin, input 110V-240V~50Hz-60Hz, output 48V, 25A
Steering and Suspension
Steering system	Single-stage rack and pinion steering system, automatic rocker compensating function
Brake system	4-wheel hydraulic disc brake + hand brake
Accelerator	Stepless speed change
Front suspension system	Independent suspension
Rear suspension system	Integrated rear end, leaf spring + shock absorber
Driving mode	Front axle drive and rear axle drive (4x4)
Gear ratio	12.49:1
Wheel & Tyre	12x7 Steel wheel, 24 x 8-12 tyre
	12x7 steel Rim in camo color
	12x7 steel rim in black color
	12X7 steel wheel, 23x8.5-12 tyre

Color

Packaging & Shipping

Container loading qty	Disassembled	Assembled
Qty/20'	4units	1units
Qty/40'	10units	3units
Qty/40'HQ	14units	3units
