Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Grader > China Motor Grader GR215 With High Quality
China Motor Grader GR215 With High Quality
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Forward Speed(km/h):
38
Reverse Speed(km/h):
23
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
160t/h Stationary Asphalt Mixing PlantNegotiableMOQ: 1 Unit -
Stationary Asphalt Mixing Plant-LB1000NegotiableMOQ: 1 Unit
-
240H/T Stationary Asphalt Mixing PlantNegotiableMOQ: 1 Unit
-
Hot Sale XS143J Single Drum 14ton Vibratory New Road Roller PriceUS$ 30,000 - 33,000MOQ: 1 Unit
-
New 2017Howo Synchronous Chip SealerUS$ 100,000 - 200,000MOQ: 1 Unit
Condition
New
Forward Speed(km/h)
38
Reverse Speed(km/h)
23
Place of Origin
Jiangsu, China
Brand Name
China brand
Model Number
GR215
Weight
16500kg
Dimension(L*W*H)
8970*2625*3470mm
Certification
ISO90001-2008, CE
After-sales Service Provided
Engineers available to service machinery overseas
Parameters of Motor Grader GR215:
| Motor Grader Basic specification | |
|---|---|
| Engine model | 6CTAA8.3 6CTA8.3 |
| Rated power/speed | 153kW/2200rpm 160kW/2200rpm |
| Dimension(LxWxH) | 8970×2625×3470mm |
| Operating weight(Standard) | 16500kg |
Motor Grader Performance specification | |
| Travelling speed ,forward | 5,8,11,19,23,38 km/h |
| Travelling speed ,reverse | 5,11,23 km/h |
| Tractive force(f=0.75) | 82KN |
| Max. gradeability | 20% |
| Tire inflation pressure | 260 kPa |
| Working hydraulic pressure | 16 MPa |
| Transmission pressure | 1.3~1.8MPa |
Motor Grader Operating specification | |
| Max. steering angle of front wheels | ±50° |
| Max. lean angle of front wheels | ±17° |
| Max. oscillation angle of front axle | ±15° |
| Max. oscillation angle of balance box | 15 |
| Frame articulation angle | ±27° |
| Min. turning radius using articulation | 7.3m |
| Motor Grader Blade | |
| Maximum lift above ground | 450mm |
| Maximum depth of cutting | 500mm |
| Maximum blade position angle | 90° |
| Blade cutting angle | 28°—70° |
| Circle reversing rotation | 360° |
| Moldboard width X height | 4270×610mm |
Our enterprise philosophy: Credibility,Integrity,Perfection,Innovation
Xuzhou Silkway Machinery &Equipment Co,Ltd. Our company is a strong-powered trading company which was founded eight years ago, we have many experience in trading machinery and also have the best way to get the best product for you.Our company is your best choice;cheaper price but better quality&service.
