Performance Parameter
| Item | PY160M | |
| Engine | Rated output (KW) | 125~129 |
| Rated rve (r/min) | 2200~2300 | |
| Operating Mass (kg) | Standard Model/with rear ripper | 14000/14750 |
| Overall Dimension | Standard Model | 8500*2600*3400 |
| Front bulldozing plate & Rear ripper Model | 9900*2600*3400 | |
| Turning | Articulated frame Angle | Left 25°/Right 25° |
| Minimum Turning Radius (mm) | ≤7500mm | |
| Maximum climbing gradient (%) | ≥25% | |
| Shovel Blade | Length* Chord Height | 3660*630mm |
| Maximum Depth in Ground | 500mm | |
| Maximum Angle of Inclination | Left 76°/Right 117° | |
| Angle of Revolution | 360° | |
| Cutting Angle Range | 36°-66° | |
| Front & Rear Axle Base | 5985 | |
| Middle & Rear Wheel Axle Base | 1542 | |
| Front & Rear Axle Wheel base | 2150 | |
| Maximum Tractive force (φ=0.75) | 72KN/76KN | |
| Operating Enviroment | Altitude (m) | 2000~4000 |
| Air Temperature | 35°~45° | |
Product Features
Cab
Full view, rops-over prevention and ultraviolet prevent. Full-view glass supplies oversized harizon and protects ultraviolet; intelligent control console has excellent controllability.
Rear Engine Cover
Noise reduction type rear engine cover. Effectively reducing noise pollution; integral appearance is elegant and novel.
Front Frame
High stiffness, and high torque resistance. The only thermoforming front frame with a big filleting box section , high torsional strength and optimal figure in the world.
Rolling circk working equipment
It is the patented product,which leads to high leveling accurancy and maintenance-free.
Heavy Duty Blade
Special heat treatment of resistance wear to increase service life of double time.
Packaging&Shipping
Our Services
Company Information
Silkway is located in the most famous construction machinery city Xuzhou, China. Our company has been specializing in construction machinery for many years, and we have abundant experience and resources for pre-sale, sale and after sale service. As a professional construction machinery exporter, our enterprise philosophy is " Credbility, Integrity, Perfection ". Our products have been exported to over 80 different countries, including Australia, U.K., Poland, Netherland, Italy, Russia, India, main countries of Africa, America, Central-Asia, Southeast Asia, Middle East etc.
XUZHOU SILKWAY MACHINERY&EQUIPMENT CO.,LTD
Add:F17, Hengmao Business Center, No6, Xi'an Road(N), Xuzhou City, Jiangsu Province, P,R.China
