Pictures for Whole Machine Motor Grader GR135:
Back Photo with 5 Teeth Rear Rippers:
Specifications for Motor Grader GR135:
GR135 | |
Basic specification | |
| Engine model | CUMMINS 6BT5.9 |
| Rated power/speed | 100/2200kw/rpm |
| Dimension(LxWxH) | 8015×2380×3050mm |
| Operating weight(Standard) | 11200kg |
Performance specification | |
| Travelling speed ,forward | 5,8,13,20,30,42km/h |
| Travelling speed ,reverse | 5,13,30km/h |
| Tractive force(f=0.8) | 61.3KN |
| Max. gradeability | 30% |
| Tire inflation pressure | 300MPa |
| Working hydraulic pressure | 16MPa |
| Transmission pressure | 1.3~1.8MPa |
Operating specification | |
| Max. steering angle of front wheels | Left / Right49° |
| Max. lean angle of front wheels | Left / Right17° |
| Max. oscillation angle of front axle | Up / down15° |
| Max. oscillation angle of balance box | Before/After 16 |
| Frame articulation angle | Left / Right27° |
| Min. turning radius using articulation | 6.6m |
Blade | |
| Maximum lift above ground | 410mm |
| Maximum depth of cutting | 515mm |
| Maximum blade position angle | 90° |
| Blade cutting angle | 54°—90° |
| Circle reversing rotation | 360° |
| Moldboard width X height | 3660×610mm |
Experienced shipping team, Guarantee delivery on time !
Be responsible for each client, Do perfect after-sale service !
Xuzhou Silkway Machinery&Equipment Co., Ltd.(abbreviated as Silkway) located in the most famous construction machinery city Xuzhou, China, where the factories,Caterpillar excavators,bulldozers and motor graders factories and Liebherr truck mixer factories are located. As a professional exporter of construction machinery, we have abundant marketing experience for construction machinery in China. Our enterprise philosophy is "Credibility, Integrity, Perfection"- C.I.P term.We can offer almost all kinds of construction machinery. These products have been exported to more than 80 countries.
