Fast Speed Double Drum Gasoline Engine Cableway Pulling Winch
Application
Double Drum Gasoline Engine Cableway Pulling Winch is used for tower erection,pole setting,stringing wire in electrical power line construction.
Winch can be modified as per requirement, such as changing curve capstan into straight even
cylindrical shape and coming with steel rope.
Characteristic
1)small size & compact structure;
2)light weight;
3)high efficiency ;
4) safe and reliable;
5) widely used.
6)easy operation
7)convenient to carry
Quality Control
We have the complete production equipments and professional production team to manage the whole process from production to packing shipment.All products will 100% test before delivery to ensure the quality.
Our Values
1,Take First-Class Quality as Target and First-class Service.
2,As Responsibility, To Succeed By Scientific Management.
3,Customer in Heart, Quality in Hand, Technology in the Lead.
Technical Data for Fast Speed Double Drum Gasoline Engine Cableway Pulling Winch
| Model Type | Overall Size(mm) | Weight(kg) | Power | Gear | Pulling Force(KN) | Pulling Speed(m/min) |
| JJM-5SQ | 1000*670*600 | 200 | 13HP Gasoline Engine | Slow | 50 | 9 |
| Quick | 26 | 18 | ||||
| Reverse/slow | 9 | |||||
| Reverse/quick | 18 |
