SA-YQ30 Hydraulic Puller for Overhead Line Transmission Project
US$ 15,000 - 55,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
XINYA
Model Number:
SA-YQ30
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
180KN Hydraulic Cable Puller SA-YQ180US$ 15,000 - 55,000MOQ: 1 Set -
60KN Hydraulic Cable Puller Used In Overhead Transmission LineUS$ 15,000 - 55,000MOQ: 1 Set
-
SA-YQ90 Hydraulic Cable Puller For Stringing Transmission Lines and ConductorsUS$ 15,000 - 55,000MOQ: 1 Set
-
SA-YQ40 Hydraulic Cable Puller For Overhead Transmission LineUS$ 15,000 - 55,000MOQ: 1 Set
-
SA-YQ30 Hydraulic Puller For Steel Wire Rope Cable Rope StringingUS$ 15,000 - 55,000MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
XINYA
Model Number
SA-YQ30
SA-YQ30 Hydraulic Puller for Overhead Line Transmission Project
Essential parameter
| Maximum linepull (kN) | 30 |
| Continuous linepull (kN) | 25 |
| Maximum linespeed (km/h) | 5 |
| Bullwheel bottom of groove diameter(mm) | Φ300 |
| Bullwheel grooves number | 7 |
| Maximum suitable steelrope diameter (mm) | Φ13 |
| Maximum through connector diameter (mm) | Φ40 |
| Engine power /speed (kW/rpm) | 31/2200 |
| Dimensions (mm) | 3200×1600×2000 |
| Weight (kg) | 1500 |
Feature :
1. Infinitely variable speed and line control ,the pull in the rope can be read on the line pull gauge .
2. The max pull for conductor –stringing operation can preset ,automatic overpull protection system .
3. Spring applied –hydraulic release brake acts automatically in case of hydraulic failure ensure to safety .
4. Attached reel winder with automatically level wind .load and unload conveniently .
Main component :
1. Chinese famous diesel engine.
2. Main pump:SAUER –SUNDSTRAND pump .main motor : SAI techniques product .
3. Radiator:AKG
4. Hydraulic instrument:WIKA
5. Mating with model GSP950 drum
