Overhead Transmission Line OPGW Stringing Pulley Blocks 660x100mm
US$ 10 - 50
MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
XINYA
Model Number:
SH
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
V Shaped Cable Rollers With Zinc Plate Finish With Steel Roller 60mm DiameterUS$ 20 - 100MOQ: 1 Set -
Draw-off Roller Cable Roller With Aluminium Roller Body Length 900 mm GalvanizedUS$ 20 - 100MOQ: 1 Set
-
Aerial Cable Stringing Roller With Hook Cable Pulley Overhead Fiber Optic Cable SheaveUS$ 10 - 60MOQ: 5 Pieces
-
10KN Load Capacity Straight Line Nylon Cable Roller Cable PulleyNegotiableMOQ: 1
-
Manhole Cable Rollers Triple Cable Pulley With Nylon Wheel 140x160mmUS$ 20 - 40MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
XINYA
Model Number
SH
Overhead Transmission Line OPGW Stringing Pulley Blocks 660x100mm
Application:
It is suitable to stringing stranded OPGW.Compression sleeves,swivel connectors,and pulling rope connectors can pass through the groove.The sheave is made in aluminum alloy or high strength nylon.The big size 508mm,660mm,822mm,916mm,1040mm nylon sheave can be lined with neoprene.
Single Wheel-Wheel material aluminum or Nylon, and it could be covered by rubber.
| Model | Wheel size Diameter x Width (mm) | Conductor size (mm2) | Rated load (kN) | Weight (kg) | Wheel material |
| SHD-120X30 | 120x30 | 25~70 | 5 | 2.1 | Aluminum |
| SHD-160X40 | 160X40 | 95~120 | 10 | 3.1 | |
| SHD-200X40 | 200X40 | 150~240 | 15 | 3.7 | |
| SHD-200X60 | 200X60 | 150~240 | 15 | 4.1 | |
| SHD-250X40 | 250X40 | 150~240 | 20 | 5.1 | |
| SHD-250X60 | 250X60 | 300~400 | 20 | 5.4 | |
| SHD-270X60 | 270X60 | 300~400 | 20 | 6.7 | |
| SHD-320X60 | 320X60 | 300~400 | 20 | 10.4 | |
| SHD-400X80 | 400X80 | 400~500 | 20 | 11.9 | |
| SHDN-120X30 | 120x30 | 25~70 | 5 | 1.5 | Nylon |
| SHDN-160X40 | 160X40 | 95~120 | 10 | 2.3 | |
| SHDN-200X40 | 200X40 | 150~240 | 15 | 2.5 | |
| SHDN-200X60 | 200X60 | 150~240 | 15 | 3.0 | |
| SHDN-250X40 | 250X40 | 150~240 | 20 | 3.6 | |
| SHDN-250X60 | 250X60 | 300~400 | 20 | 3.8 | |
| SHDN-270X60 | 270X60 | 300~400 | 20 | 4.3 | |
| SHDN-320X60 | 320X60 | 300~400 | 20 | 7.5 | |
| SHDN-400X80 | 400X80 | 400~500 | 20 | 8 | |
| SHD-508X75 | 508X75 | ≤400 | 20 | 22.3 | Aluminum |
| SHD-660X100 | 660X100 | ≤500 | 20 | 30 | |
| SHDN-508X75 | 508X75 | ≤400 | 20 | 18 | Nylon |
| SHDN-660X100 | 660X100 | ≤500 | 20 | 20 | |
| SHDN-830X110 | 830X110 | ≤630 | 30 | 25 | |
| SHDN-916X110 | 916X110 | ≤800 | 50 | 45 | |
| SHDN-1040X125 | 1040X125 | ≤1000 | 55 | 105 |
Note:
1. Hook fitting,round eye fitting and clevis fitting are optional,please specify when ordering.Customized blocks could be supplied on request.The data in the model mean the outer diameter of sheave x widthof sheave(mm).
2. All the sheaves are mounted on ball bearings.Thel frame of blocks is made in galvanized steel.
