CNC Hydraulic Swing Beam Shearing Machine

Zhengzhou Timeway Machine Tool Co., Ltd.
CNC Hydraulic Swing Beam Shearing Machine thumbnail-1
CNC Hydraulic Swing Beam Shearing Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
TIMAC
Model Number:
CSS- series
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name TIMAC
Model Number CSS- series
Condition New

Specifications

1.CNC hydraulic swing beam shearing machine;
2.Different shearing thickness and width;
3.Single, automatic continuous shearing

Features:

1. Hydraulic drive, swing beam tool post.

2. The frame adopts integrity welding structure with better rigidity.

3. Nitrogen cylinder or accumulator are usd to return, stability and quickly.

4. A speed blades gap adjusting device permits to adjust stepless the blades gap.

5. The stroke and frequency of shearing can be controlled.

6. Single shearing and automatic continuous shearing.

7. CNC system and position encoder form the closed loop controlled system, ensuring high precision and good stability.

8. After inputting precomputed data, the back gauge can be automatically moved, positioned and stopped.



Specification

Shearing size

Shearing angle

Strokes

Adjustment range

Motor power

Dimension (LxWxH)

(TxW) mm

°

time/min

mm

kw

mm

CSS-4x2500

4x2500

 1°30'

20

20-600

4

2900x1500x1500

CSS-4x3200

4x3200

 1°30'

18

20-600

5.5

3600x1675x1650

CSS-6x2500

6x2500

 1°30'

18

20-600

7.5

2950x1530x1600

CSS-6x3200

6x3200

 1°30'

14

20-600

7.5

3650x1675x1650

CSS-6x4000

6x4000

 1°30'

14

20-600

7.5

4550x1850x1700

CSS-6x5000

6x5000

 1°30'

10

20-600

18.5

5550x2100x1950

CSS-6x6000

6x6000

 1°30'

10

20-600

18.5

6560x2550x2100

CSS-8x2500

8x2500

 1°30'

14

20-600

11

2950x1530x1600

CSS-8x3200

8x3200

 1°30'

10

20-600

11

3650x1540x1650

CSS-8x4000

8x4000

 1°30'

8

20-600

11

4550x1850x1700

CSS-8x5000

8x5000

 1°30'

7

20-800

15

5550x2100x1950

CSS-8x6000

8x6000

 1°30'

6

20-800

15

6550x2550x2100

CSS-10x2500

10x2500

 1°30'

14

20-800

15

3030x1850x1850

CSS-10x3200

10x3200

 1°30'

12

20-800

15

3840x1910x1800

CSS-10x4000

10x4000

 1°30'

12

20-800

15

4500x2000x1850

CSS-12x2500

12x2500

 1°30'

16

20-800

18.5

3050x1860x1850

CSS-12x3200

12x3200

 1°30'

14

20-800

18.5

3845x1930x2000

CSS-12x4000

12x4000

 1°30'

14

20-800

18.5

4550x2100x2050

CSS-12x5000

12x5000

 1°30'

7

20-1000

30

6100x2970x3050

CSS-12x6000

12x6000

 1°30'

6

20-1000

37

6800x3100x3050

CSS-12x8000

12x8000

 1°30'

5

20-1000

37

9150x3575x3150
